Fuyuang Industrial Battery Charger 48V-96V 10A-30A up to 3000W for Forklift, Electric Pallet Jack and AGV

Fuyuang Industrial Battery Charger 48V-96V 10A-30A up to 3000W for Forklift, Electric Pallet Jack and AGV

Name: Fuyuang Industrial Battery Charger 48V-96V 10A-30A up to 3000W for Forklift, Electric Pallet Jack and AGV
Brand: Fuyuang
Rating: 5.0 (84 reviews)

The FY58810000 is an industrial-grade battery charger designed for 48V, 60V, 72V and 96V traction battery systems, including forklifts, electric pallet jacks and AGVs. It offers 10A, 20A and 30A output options with 58.8V 10A, 58.4V 10A, 54.6V 10A and 50.4V 10A versions available from the same platform, and the platform power range reaches 3000W. The charger runs from a 100-240Vac 50/60Hz input with active PFC, uses a CC-CV-trickle charge profile with stop charge, and reports status through a red/green LED indicator. Over-voltage, over-current, overload, over-temperature and short-circuit protection are included, and the housing is IP21 rated with IP67 protection available as an option. A CAN bus interface is available for fleet and system integration. Fuyuan Electronic Co., Ltd has manufactured chargers since 2005, operates 108,000 m2 of production space, runs a CNAS-standard EMC laboratory, and has developed 3,000+ models from 60W to 10KW. This charger carries a 3-year warranty.

Model:
FY58810000
Brand:
Fuyuang
Code:
FY58810000


Availability:

Product Overview

The FY58810000 is a high-current industrial battery charger for 48V to 96V traction batteries used in forklifts, electric pallet jacks, AGVs and similar material handling equipment. Outputs of 10A, 20A and 30A are available, with 58.8V 10A, 58.4V 10A, 54.6V 10A and 50.4V 10A variants on the same platform and platform power reaching 3000W. The unit accepts 100-240Vac 50/60Hz input with active PFC and charges with a CC-CV-trickle profile and stop charge function. The enclosure is IP21 rated as standard with IP67 protection available as an option, and a CAN bus interface can be specified for fleet monitoring and system integration.

Key Features

• Industrial charger for 48V, 60V, 72V and 96V traction batteries • 10A, 20A and 30A output options with platform power up to 3000W • 100-240Vac 50/60Hz input with active PFC • CC-CV-trickle charge profile with stop charge • IP21 housing with optional IP67 protection • CAN bus interface available for fleet monitoring • Over-voltage, over-current, overload, over-temperature and short-circuit protection • Fanless cooling by free air convection with red/green LED indicator

Technical Specifications

• Model: FY58810000 • Input: 100-240Vac, 50/60Hz • Output options: 58.8V 10A / 58.4V 10A / 54.6V 10A / 50.4V 10A • Current range: 10A / 20A / 30A • Platform power: 90W / 120W / 150W / 200W / 450W / 600W / 3000W • Voltage coverage: 48V, 60V, 72V, 96V battery systems • Charge mode: CC-CV-Trickle Charge, stop charge • Ingress protection: IP21 standard, IP67 optional • Housing: PC fireproof material, black • Certification: UL, cUL, FCC, CE, GS, CB, UKCA, KC, PSE, SAA, CCC, NOM, RoHS, REACH • OEM/ODM: acceptable

Applications

• Forklift battery charging • Electric pallet jacks • Automated guided vehicles (AGVs) • E-bikes and scooters • Golf carts • Industrial electric vehicles

Customization & Service

Fuyuan Electronic Co., Ltd supports OEM and ODM development on this platform, including custom output voltage and current, custom DC connectors, private labeling, LOGO printing and custom packaging. Development is supported by a CNAS-standard EMC laboratory, and high-power and non-standard voltage projects can be engineered to order. Every unit is covered by a 3-year warranty and receives 4-8 hours of full-load burn-in plus 100% factory inspection. MOQ is confirmed per model.
