Fuyuang FY2402500 29.4V 2.5A 80W Intelligent Lithium Battery Charger for 24V E-bike, Scooter, Drone and Robot Packs

Fuyuang FY2402500 29.4V 2.5A 80W Intelligent Lithium Battery Charger for 24V E-bike, Scooter, Drone and Robot Packs

Name: Fuyuang FY2402500 29.4V 2.5A 80W Intelligent Lithium Battery Charger for 24V E-bike, Scooter, Drone and Robot Packs
Brand: Fuyuang
Rating: 5.0 (66 reviews)

The Fuyuang FY2402500 is an 80W intelligent lithium battery charger with a 29.4V 2.5A output, sized for 7S 24V packs used on e-bikes, electric scooters, robots, drones, electric tools and similar equipment. It accepts 100-240Vac 50/60Hz and charges at efficiency above 89%. Charging is automatic and follows a CC-CV-trickle profile with stop charge, so the pack is brought to full capacity and then taken off charge. Short circuit, overload, over-voltage and over-temperature protection keep the charger and battery safe, and a red / green LED indicator makes status easy to read at a distance. The fanless PC fireproof housing cools by free air convection. Fuyuan Electronic Co., Ltd has manufactured chargers and power supplies since 2005, with 108,000 m2 of production space and a CNAS-standard EMC laboratory. Certification routes for this platform include UL, CE, GS, FCC, PSE, SAA, KC, RoHS and REACH, issued per model and destination, with a 3-year warranty.

Model:
FY2402500
Brand:
Fuyuang
Code:
FY2402500


Availability:

Product Overview

The FY2402500 is an 80W intelligent charger for lithium battery packs, delivering 29.4V at 2.5A. It targets 7S 24V packs on e-bikes, electric scooters, balance vehicles, drones, robots and electric tools. The charger runs automatically once connected: it detects the battery, charges at the configured CC-CV-trickle profile and stops when the pack is full, with no manual setting required.

Key Features

• 29.4V 2.5A output for 7S 24V lithium battery packs • 80W rated power, intelligent automatic charging • 100-240vac 50/60Hz universal AC input • CC-CV-trickle charge mode with stop charge • Charging efficiency higher than 89% • Short circuit, overload, over-voltage and over-temperature protection • Red / green LED indicator, black fanless housing • Fanless cooling by free air convection with PC fireproof material

Technical Specifications

• Model: FY2402500 • Product name: 80W lithium battery charger • Input: 100-240vac, 50-60Hz • Output: 29.4V 2.5A • Output power: 80W • Battery: 7S 24V lithium battery pack • Charge mode: CC-CV-trickle charge / stop charge • Charging efficiency: higher than 89% • LED/LCD indicator: red / green • Housing: PC fireproof material, black, fanless • Certification: UL, cUL, ETL, FCC, CE, GS, CB, UKCA, PSE, SAA, KC, CCC, NOM, RoHS, REACH routes per model and destination • MOQ: 10 PCS

Applications

• Electric bicycles and e-bike packs • Electric scooters and balance vehicles • Drones and UAV battery packs • Service, cleaning and delivery robots • Electric power tools • Portable equipment and battery packs

Customization & Service

OEM and ODM projects are accepted, covering custom output voltage and current, DC connector and cable, housing colour, indicator behaviour, private labeling, LOGO printing and packaging. Designs pass through an in-house CNAS-standard EMC laboratory before certification so that compatibility issues are found early. Units are 100% factory inspected and receive full-load burn-in, and the charger carries a 3-year warranty. This model starts from a low MOQ of 10 PCS, which supports trial orders before volume production.
