Fuyuang FY2904000 Smart 29.2V 4A-30A 24V Battery Charger for Electric Scooters, E-bikes and LiFePO4 Packs

Fuyuang FY2904000 Smart 29.2V 4A-30A 24V Battery Charger for Electric Scooters, E-bikes and LiFePO4 Packs

Name: Fuyuang FY2904000 Smart 29.2V 4A-30A 24V Battery Charger for Electric Scooters, E-bikes and LiFePO4 Packs
Brand: Fuyuang
Rating: 5.0 (90 reviews)

The Fuyuang FY2904000 is a smart 29.2V battery charger for 24V systems, with output current options from 4A up to 30A and power ratings of 116W to 120W. It charges lithium, lead-acid and LiFePO4 battery packs, covering electric scooters, e-bikes and battery pack assembly. Input is 100-240V 50/60Hz at 1.5A and efficiency is above 89%. Protection covers short circuit, overload, over-voltage and over-temperature. The charger measures 154 x 60 x 36 mm in a fireproof PC housing, with both DC and AC ports. Fuyuan Electronic Co., Ltd has manufactured chargers since 2005, with 108,000 m2 of production space and 450 employees. Every unit carries a 3-year warranty.

Model:
FY2904000
Brand:
Fuyuang
Code:
FY2904000


Availability:

Product Overview

The FY2904000 is a smart 29.2V battery charger for 24V systems, covering lithium, lead-acid and LiFePO4 battery packs. Output current versions range from 4A to 30A, with typical power ratings of 116W and 120W. Input is 100-240V 50/60Hz at 1.5A, efficiency is above 89%, and short circuit, overload, over-voltage and over-temperature protection are built in. The compact 154 x 60 x 36 mm housing uses fireproof PC material.

Key Features

• Smart 29.2V charger for 24V battery systems • Output current options from 4A to 30A, 116W-120W • Charges lithium, lead-acid and LiFePO4 battery packs • 100-240V 50/60Hz, 1.5A universal AC input • Efficiency above 89% • Short circuit, overload, over-voltage and over-temperature protection • Compact 154 x 60 x 36 mm housing with DC and AC ports • Colors: black, white or customized

Technical Specifications

• Model: FY2904000 • Product type: smart lithium / lead-acid / LiFePO4 battery charger • Input: 100-240V, 1.5A, 50/60Hz • Output: 29.2V 4A-30A • Output power: 116W / 120W • Efficiency: >89% • Protection: short circuit, overload, over-voltage, over-temperature • Port: DC and AC • Dimension: 154 x 60 x 36 mm • Material: PC fireproof material • Color: black, white or customized • Certification: UL, cUL, GS, CE, SAA, KC, PSE, CB, FCC, RoHS, REACH • Warranty: 3 years

Applications

• Electric scooters and robot scooters • E-bikes and electric vehicles • Battery packs for 24V systems • Medical equipment • Robots and automation

Customization & Service

Fuyuan Electronic Co., Ltd supports OEM and ODM projects on this charger, including custom output voltage and current, custom DC connectors, private labeling and LOGO printing. The CNAS-standard EMC laboratory supports EMC verification before formal certification. Each charger is 100% factory inspected, receives 4-8 hours of full-load burn-in and carries a 3-year warranty. MOQ is 100 PCS.
