Name: Fuyuang FY2944000 Custom 24V-96V LiFePO4 Battery Charger for Golf Cart, E-bike, Electric Scooter and Forklift Battery Packs
Brand: Fuyuang
Rating: 5.0 (28 reviews)

The Fuyuang FY2944000 golf cart and industrial variant charges lithium and LiFePO4 packs from 24V through 36V, 48V, 60V, 72V, 84V and 96V, with output current between 2A and 5A and a 90W to 600W power band. It is aimed at golf carts, e-bikes, electric scooters, forklifts and similar electric vehicles that need consistent charging across a mixed fleet. A CC-CV-trickle charge profile with stop-charge endpoint keeps the pack full without overcharging. Short circuit, overload, over-voltage and over-temperature protection are included, and a red / green indicator shows whether charging is in progress or complete. Cooling is fanless by free air convection, which removes fan maintenance and dust intake on workshop equipment. Fuyuan Electronic Co., Ltd has manufactured chargers and power supplies since 2005, with 108,000 m2 of production space, a CNAS-standard EMC laboratory and 3,000+ developed models from 60W to 10KW. This charger carries a 3-year warranty.

Model:
FY2944000
Brand:
Fuyuang
Code:
FY2944000


Availability:

Product Overview

This FY2944000 configuration is designed for higher capacity electric vehicles: golf carts, e-bikes, electric scooters and forklifts running lithium or LiFePO4 packs between 24V and 96V. Output current is set between 2A and 5A depending on pack capacity. Because the platform covers a wide voltage band, a fleet or dealer can standardise on one charger family while still matching individual vehicle voltages.

Key Features

• Covers 24V, 36V, 48V, 60V, 72V, 84V and 96V battery packs • Suits LiFePO4, lithium-ion and lead-acid battery types • 100-240Vac 50/60Hz universal AC input • Power range from 90W to 600W with 2A to 5A output • CC-CV-trickle charge mode with stop-charge endpoint • Charging efficiency higher than 89% • Short circuit, overload, over-voltage and over-temperature protection • Fanless free-air convection cooling with red / green status indicator

Technical Specifications

• Model: FY2944000 • Input: 100-240Vac, 50-60Hz • Output voltage variants: 24V / 36V / 48V / 60V / 72V / 84V / 96V • Output current variants: 2A / 3A / 5A • Power range: 90W / 120W / 150W / 200W / 450W / 600W • Battery type: LiFePO4, lithium-ion, lead-acid • Charging mode: CC-CV-trickle charge / stop charge • Charging efficiency: higher than 89% • Housing: PC fireproof material, fanless • Protection: OVP, OTP, OLP, overcurrent, overvoltage, short circuit • Certification: UL, cUL, FCC, CE, GS, CB, UKCA, KC, PSE, SAA, CCC, NOM, RoHS, REACH • MOQ: 100 PCS

Applications

• Golf carts and utility vehicles • Electric forklifts and warehouse trucks • Electric scooters and e-bikes • Industrial electric vehicles and AGVs • Battery pack assembly and service workshops • Energy storage and power station batteries

Customization & Service

OEM and ODM customization is available on output voltage, output current, DC connector and cable, housing, protection logic, indicator behaviour, private labeling, LOGO printing and packaging. Optional functions include reverse-polarity protection, timer charging, anti-spark, pre-charging, automatic shut-off and CAN 2.0 / RS485 communication for fleet monitoring. Every unit is 100% factory inspected with 4-8 hours of full-load burn-in and covered by a 3-year warranty, with an MTBF of 30,000 hours or more. Standard MOQ is 100 PCS.
