Fuyuang IP67 Waterproof Golf Cart Battery Charger 24V-72V 10A-25A for LiFePO4 Lithium and Lead Acid Battery Packs

Fuyuang IP67 Waterproof Golf Cart Battery Charger 24V-72V 10A-25A for LiFePO4 Lithium and Lead Acid Battery Packs

Name: Fuyuang IP67 Waterproof Golf Cart Battery Charger 24V-72V 10A-25A for LiFePO4 Lithium and Lead Acid Battery Packs
Brand: Fuyuang
Rating: 5.0 (16 reviews)

The FY29210000 from Fuyuang is a sealed IP67 waterproof battery charger developed for golf carts and other outdoor electric vehicles that have to be charged in wet, dusty or coastal conditions. It runs from a universal 100-240Vac 50/60Hz input and delivers a 29.2V 10A output, while the same platform spans 24V, 29.2V, 36V, 48V and 72V battery systems at 10A to 25A. Charging follows a CC-CV-trickle profile so packs are filled quickly and then held safely, with over-voltage, over-current, overload, over-temperature and short-circuit protection on board. Free-air convection cooling removes the need for a fan, keeping operation quiet and preventing dust from being drawn into the enclosure. The housing is made from PC fireproof material and a 3-pin round plug is available for common golf cart charge ports.

Model:
FY29210000
Brand:
Fuyuang
Code:
FY29210000


Availability:

Product Overview

The FY29210000 is an IP67 waterproof battery charger built for golf carts and outdoor electric vehicles that are charged in rain, spray and dust. It accepts 100-240Vac 50/60Hz worldwide input and provides a 29.2V 10A output, with the platform covering 24V, 29.2V, 36V, 48V and 72V packs at 10A to 25A. Charging uses a CC-CV-trickle profile with automatic stop, and the sealed fanless housing keeps the electronics protected while running quietly. LiFePO4, lithium-ion and lead-acid batteries are all supported, and a 3-pin round plug can be fitted to match golf cart charge ports.

Key Features

• IP67 waterproof sealed enclosure for golf carts and wet outdoor charging • Universal 100-240Vac 50/60Hz input for worldwide operation • Platform covers 24V, 29.2V, 36V, 48V and 72V systems at 10A to 25A • CC-CV-trickle charging profile with automatic stop • Charging efficiency above 89% • Fanless design, cooling by free air convection, with no noise • Protection against over-voltage, over-current, overload, over-temperature and short circuit • Red/green LED status indicator and 3-pin round plug option

Technical Specifications

• Model: FY29210000 • Input: 100-240Vac, 50/60Hz • Output: 29.2V 10A • Platform voltage range: 24V / 29.2V / 36V / 48V / 72V • Platform current range: 10A to 25A • Platform power: 90W / 120W / 150W / 200W / 450W / 600W • Battery compatibility: LiFePO4, lithium-ion, lead-acid • Charge mode: CC-CV-Trickle Charge, stop charge • Charging efficiency: above 89% • Ingress protection: IP67 waterproof • Housing: PC fireproof material, black • Certification: UL, cUL, FCC, CE, GS, CB, UKCA, KC, PSE, SAA, CCC, NOM, RoHS, REACH • MOQ: 100 PCS

Applications

• Golf cart battery charging • E-bikes and scooters • Robots and AGV equipment • Drones • Electric tools • Marine and outdoor equipment

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on this platform, including custom output voltage and current, custom DC and AC connectors, private labeling, LOGO printing and custom packaging. Engineering work is supported by a CNAS-standard EMC laboratory, so compliance preparation can start before formal certification and the development cycle can be shortened. Every unit is covered by a 3-year warranty and receives 4-8 hours of full-load burn-in plus 100% factory inspection. Standard MOQ is 100 PCS.
