Fuyuang IP67 Waterproof 29.2V 2A Battery Charger for Marine, Boat, Solar and Outdoor Battery Systems

Fuyuang IP67 Waterproof 29.2V 2A Battery Charger for Marine, Boat, Solar and Outdoor Battery Systems

Name: Fuyuang IP67 Waterproof 29.2V 2A Battery Charger for Marine, Boat, Solar and Outdoor Battery Systems
Brand: Fuyuang
Rating: 5.0 (80 reviews)

The FY2922000 is a fully sealed IP67 waterproof battery charger built for installations where water, dust and salt air are unavoidable, such as boats, jet skis and outdoor solar systems. It delivers 29.2V 2A from a 100-240Vac 50/60Hz input, and the platform covers 12V, 24V, 29.2V, 36V, 48V and 72V battery systems. The electronics are fully potted so the housing is dustproof and corrosion resistant, and the charger runs across an operating temperature range of -20C to +60C. Charging follows a CC-CV-trickle profile with automatic stop, with over-voltage, over-current, overload, over-temperature, low-tension and short-circuit protection included. Fuyuan Electronic Co., Ltd has produced chargers since 2005, operates 108,000 m2 of production space, maintains a CNAS-standard EMC laboratory, and has developed 3,000+ models from 60W to 10KW. A 3-year warranty applies to this charger.

Model:
FY2922000
Brand:
Fuyuang
Code:
FY2922000


Availability:

Product Overview

The FY2922000 is an IP67 waterproof battery charger for wet, dusty and salt-air environments including boats, jet skis, electric fences and solar installations. It provides 29.2V 2A from a universal 100-240Vac input, with the platform extending across 12V to 72V battery systems. The charger is fully potted, dustproof and corrosion resistant, and works from -20C to +60C. LiFePO4, lithium-ion and lead-acid batteries are supported, with CC-CV-trickle charging and automatic stop.

Key Features

• IP67 waterproof and dustproof sealed construction • Fully potted electronics resist moisture, dust and corrosion • 29.2V 2A output with 12V to 72V platform coverage • Operating temperature range of -20C to +60C • Universal 100-240Vac 50/60Hz input • CC-CV-trickle charging with stop charge • Protection: over-voltage, over-current, overload, over-temperature, low tension and short circuit • Fanless cooling by free air convection, quiet operation

Technical Specifications

• Model: FY2922000 • Input: 100-240Vac, 50/60Hz • Output: 29.2V 2A • Platform voltage range: 12V / 24V / 36V / 48V / 72V • Platform power: 90W / 120W / 150W / 200W / 450W / 600W • Battery compatibility: LiFePO4, lithium-ion, lead-acid • Charge mode: CC-CV-Trickle Charge, stop charge • Ingress protection: IP67 waterproof • Operating temperature: -20C to +60C • Housing: PC fireproof material, black • Certification: UL, cUL, FCC, CE, GS, CB, UKCA, KC, PSE, SAA, CCC, NOM, RoHS, REACH • MOQ: 100 PCS

Applications

• Marine and boat battery charging • Jet ski and personal watercraft • Solar and renewable energy storage • Outdoor and remote equipment • Electric fence power • Cameras and security equipment • Industrial and household appliances

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on this waterproof platform, including custom output voltage and current, custom DC connectors and AC plugs, private labeling, LOGO printing and custom packaging. The CNAS-standard EMC laboratory supports pre-compliance testing during development. Every unit is covered by a 3-year warranty and receives 4-8 hours of full-load burn-in plus 100% factory inspection. Standard MOQ is 100 PCS.
