Fuyuang IP67 Battery Charger 29.2V-84V 5A-20A for Marine, AGV, AMR and Robotics Battery Packs

Fuyuang IP67 Battery Charger 29.2V-84V 5A-20A for Marine, AGV, AMR and Robotics Battery Packs

Name: Fuyuang IP67 Battery Charger 29.2V-84V 5A-20A for Marine, AGV, AMR and Robotics Battery Packs
Brand: Fuyuang
Rating: 5.0 (3 reviews)

The Fuyuang FY5840000 is an IP67 intelligent fast charger for marine, AGV, AMR, robotics and industrial battery systems. It delivers 54.6V 20A (1092W) from a 100-240Vac 50/60Hz input, and the platform offers 29.2V, 43.8V, 54.6V, 58.4V, 67.2V, 73V and 84V outputs at 5A or 10A. The charger reaches 95% efficiency and uses fanless free-air convection cooling for quiet operation. Protection covers fireproof material, low-tension, over-charging, over-current, over-voltage and short circuit, and connector choices include 5.5*2.5, 5.5*2.1, XLR, RCA, Anderson and XT30. Manufactured by Fuyuan Electronic Co., Ltd since 2005, with 108,000 m2 of production space, 450 employees, a CNAS-standard EMC laboratory, 3,000+ developed models from 60W to 10KW, and a 3-year warranty on this product.

Model:
FY5840000
Brand:
Fuyuang
Code:
FY5840000


Availability:

Product Overview

The FY5840000 is a sealed IP67 charger built for marine, robotics and industrial installations where moisture and dust are present. It supplies 54.6V 20A (1092W) and is compatible with 29.2V to 84V LiFePO4, lithium-ion and lead-acid battery packs. A 100-240Vac input, 95% efficiency and fanless convection cooling make the unit simple to integrate, while the multi-stage protection set and choice of professional DC connectors suit both OEM and retrofit projects.

Key Features

• IP67 sealing with intelligent charging and fast-charge capability • 54.6V 20A (1092W) output from a 100-240Vac 50/60Hz input • Output variants: 58.4V 10A / 54.6V 10A / 43.8V 10A / 29.2V 10A / 58.4V 5A / 29.2V 5A / 43.8V 5A / 54.6V 5A / 67.2V 5A / 73V 10A / 84V 10A • 95% charging efficiency with fanless free-air convection cooling • Protection: fireproof, low tension, over-charging, over-current, over-voltage and short circuit • Connectors: 5.5*2.5 / 5.5*2.1 / XLR / RCA / Anderson / XT30 / OEM • Private mould housing in ABS, aluminium alloy and fireproof PC • 3-year warranty with 4-8 hours full-load burn-in

Technical Specifications

• Model: FY5840000 • Input: 100-240Vac 50/60Hz (customizable) • Output: 54.6V 20A (1092.0W), customizable • Output variants: 29.2V, 43.8V, 54.6V, 58.4V, 67.2V, 73V, 84V at 5A or 10A • Platform power range: 24W to 3000W • Efficiency: 95%; fanless free-air convection cooling • Housing material: ABS, aluminium, aluminium alloy, fireproof PC; colour black • Certification: UL, CE, GS, ETL, SAA, KC, FCC, PSE, RoHS, REACH, UKCA, KCC • MOQ: 10 PCS

Applications

• Marine and offshore battery systems • AGVs, AMRs and service robots • Robotics and industrial automation • Electric tools • Home security systems and household appliances • Medical devices • Motorcycles and scooters

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on this platform, covering custom output voltage and current, charging profiles, DC connectors, AC plugs, cable length, housing colour, private labeling, LOGO printing and packaging. Engineering work is supported by a CNAS-standard EMC laboratory, so compliance testing can be prepared before formal certification and the development cycle shortened; custom projects can reach engineering completion in as little as 10 days. Every unit is covered by a 3-year warranty, is 100% factory inspected and receives 4-8 hours of full-load burn-in. Standard MOQ for this item is 10 PCS. Certifications held on this platform include UL, CE, GS, ETL, SAA, KC, FCC, PSE, RoHS, REACH, UKCA and KCC.
