Fuyuang FY5462000 12V-67.2V 60W-800W LiFePO4 / Lithium E-bike and Scooter Battery Charger with XLR or Anderson Connector

Fuyuang FY5462000 12V-67.2V 60W-800W LiFePO4 / Lithium E-bike and Scooter Battery Charger with XLR or Anderson Connector

Name: Fuyuang FY5462000 12V-67.2V 60W-800W LiFePO4 / Lithium E-bike and Scooter Battery Charger with XLR or Anderson Connector
Brand: Fuyuang
Rating: 5.0 (21 reviews)

The Fuyuang FY5462000 is a desktop lithium and LiFePO4 battery charger covering 60W to 800W, with output settings that include 12V 5A, 16.8V 5A, 24V 8A, 29.4V 8A, 36V 4A, 42V 5A, 48V 10A, 54.6V 6A, 58.4V 10A and 67.2V 5A. It runs from 100-240Vac 50/60Hz and reaches 95% efficiency, so it charges fast with less heat. Connector choice is one of the practical advantages of this platform: 5.5*2.5mm, 5.5*2.1mm, XLR, RCA, Anderson or an OEM connector can be fitted to match the vehicle charging port. Protection covers over-current, over-voltage, short circuit, low tension, over-charging and fire risk from the 94-V0 flame-retardant housing, and the fanless design keeps noise low. Fuyuan Electronic Co., Ltd has built chargers since 2005, with 108,000 m2 of production space, a CNAS-standard EMC laboratory and 3,000+ developed models from 60W to 10KW. This charger carries a 3-year warranty.

Model:
FY5462000
Brand:
Fuyuang
Code:
FY5462000


Availability:

Product Overview

The FY5462000 is a desktop charger family for lithium and LiFePO4 packs used on e-bikes, scooters, drones and similar equipment. It spans 60W to 800W with common outputs from 12V 5A through 24V 8A, 36V 4A, 42V 5A, 48V 10A, 54.6V 6A, 58.4V 10A and 67.2V 5A. A 100-240Vac 50/60Hz input and 95% efficiency make it suitable for everyday charging, and the DC connector can be specified as 5.5*2.5mm, 5.5*2.1mm, XLR, RCA, Anderson or OEM.

Key Features

• Supports 12V, 24V, 36V, 48V, 54.6V, 58.4V and 67.2V battery packs • Power range from 60W to 800W • Fast charging with up to 95% efficiency • 100-240Vac 50/60Hz universal AC input • Connector options: 5.5*2.5 / 5.5*2.1 / XLR / RCA / Anderson / OEM • Fireproof housing with over-charging, over-current and over-voltage protection • Low tension and short circuit protection, fanless low-noise design • Certified to ETL, GS, CE, SAA, PSE, KC, FCC, RoHS and REACH

Technical Specifications

• Model: FY5462000 • Input: 100-240Vac 50/60Hz • Output options: 12V 5A / 16.8V 5A / 24V 8A / 29.4V 8A / 36V 4A / 37.8V 3A / 42V 5A • Output options (continued): 48V 10A / 54.6V 6A / 58.4V 10A / 67.2V 5A • Power range: 60W / 75W / 80W / 120W / 150W / 200W / 210W / 250W / 300W / 400W / 600W / 800W • Charging efficiency: 95% • Connector: 5.5*2.5 / 5.5*2.1 / XLR / RCA / Anderson / OEM • Housing: ABS and PC fireproof material • Colors: black, white, gray • Protection: short circuit, over-current, over-voltage, low tension, over-charging, fireproof • Certification: ETL, GS, CE, SAA, PSE, KC, FCC, RoHS, REACH, UL, UKCA • MOQ: 100 PCS

Applications

• Electric bicycles and e-bike packs • Electric scooters and mopeds • Drones and UAV batteries • Household electrical appliances • Industrial equipment and electric tools • Medical devices and mobility equipment • Home security systems and monitoring devices

Customization & Service

This platform is produced in a private mold and accepts custom voltage, custom current, custom DC connectors, custom AC plugs and custom packaging, plus private labeling and LOGO printing. Charging profiles can be set for lithium CC-CV or lead-acid three-stage charging, and CAN 2.0B or RS485 Modbus RTU communication is available for fleet integration. Fuyuan Electronic Co., Ltd validates each design in a CNAS-standard EMC laboratory before certification and 100% inspects every unit. The product carries a 3-year warranty. Standard MOQ is 100 PCS.
