Fuyuang FY4202000 42V 2A / 54.6V 2A Li-ion Battery Charger for 36V E-bike, Scooter and Portable Power Station Packs

Fuyuang FY4202000 42V 2A / 54.6V 2A Li-ion Battery Charger for 36V E-bike, Scooter and Portable Power Station Packs

Name: Fuyuang FY4202000 42V 2A / 54.6V 2A Li-ion Battery Charger for 36V E-bike, Scooter and Portable Power Station Packs
Brand: Fuyuang
Rating: 5.0 (89 reviews)

The Fuyuang FY4202000 is a light, compact charger delivering 42V 2A for 36V lithium battery packs, with 42V 3A, 42V 4A and 54.6V 2A settings also available. It runs from 100-240V 50-60Hz and uses a fanless plastic case, which keeps the unit quiet and makes it suitable for home and office charging. Efficiency is above 95%, and the charger includes short circuit, over-current, over-voltage and reverse-polarity protection so that a mis-connected pack does not damage the electronics. Charging is intended for 10S 36V lithium packs used on e-bikes, scooters and portable power stations, as well as robots, heaters and motor-driven equipment. Fuyuan Electronic Co., Ltd has manufactured battery chargers since 2005 with two production bases, 108,000 m2 of floor space and a CNAS-standard EMC laboratory. This charger carries a 3-year warranty.

Model:
FY4202000
Brand:
Fuyuang
Code:
FY4202000


Availability:

Product Overview

The FY4202000 is a 42V 2A charger for 36V lithium-ion battery packs, with 42V 3A, 42V 4A and 54.6V 2A options and full custom settings on request. A 100-240V 50-60Hz input and a compact 133*58*31MM housing weighing 0.4kgs make it easy to carry and deploy. It is used on e-bikes, electric scooters, portable power stations, robots and motor-driven equipment where a 10S pack has to be topped up from a standard wall socket.

Key Features

• 42V 2A output for 36V (10S) lithium-ion battery packs • Additional settings of 42V 3A, 42V 4A and 54.6V 2A, custom available • 100-240V 50-60Hz universal AC input • Charging efficiency higher than 95% • Short circuit, over-current, over-voltage and reverse-polarity protection • Fanless plastic case with PC fireproof material • Customisable DC connector to match your pack or charging port • Compact 133*58*31MM body weighing 0.4kgs

Technical Specifications

• Model: FY4202000 • Product name: 42V 2A lithium battery charger • Input: 100-240V 50-60Hz • Output: 42V 2A / 42V 3A / 42V 4A / 54.6V 2A, custom • Power options: 84W / 126W / 168W / 210W, custom • Charging efficiency: higher than 95% • Dimension: 133*58*31MM, weight 0.4kgs • Housing: plastic case, fanless, black, PC fireproof material • DC connector: customised as per your demands • Protection: short circuit, over-current, over-voltage, reverse polarity • Certification: UL, ETL, CE, FCC, TUV-GS, PSE, SAA, KC, CCC, RoHS, REACH • MOQ: 100 PCS

Applications

• Electric bicycles and e-bike packs • Electric scooters and mopeds • Portable power stations • Robots and service equipment • Electric heaters and motor-driven appliances • Battery pack assembly and testing

Customization & Service

OEM and ODM orders are welcome: output voltage and current, DC connector and cable, housing and colour, private labeling, LOGO printing and packaging can be specified. Input and output fuses give double-layer protection against over-current and short-circuit conditions, and optional timer charging and automatic shut-off are available. Units are 100% factory inspected with full-load burn-in and carry a 3-year warranty, backed by an in-house CNAS-standard EMC laboratory. Standard MOQ is 100 PCS.
