Fuyuang FY2942000 3-Pin DIN 29.4V 2A 58.8W Battery Charger for iRobot Roomba, E-bike and Golf Cart Packs

Fuyuang FY2942000 3-Pin DIN 29.4V 2A 58.8W Battery Charger for iRobot Roomba, E-bike and Golf Cart Packs

Name: Fuyuang FY2942000 3-Pin DIN 29.4V 2A 58.8W Battery Charger for iRobot Roomba, E-bike and Golf Cart Packs
Brand: Fuyuang
Rating: 5.0 (65 reviews)

The Fuyuang FY2942000 is a 3-pin DIN power supply and lithium battery charger with a 29.4V 2A output rated 58.8W. It charges 7S lithium packs and is used with iRobot Scooba and Roomba vacuum cleaners, e-bikes and electric golf carts. Input is 100-240V at 0.9A and charging follows a CC-CV-floating charge profile. Protection covers short circuit, overload, over-voltage and over-temperature. The charger measures 113 x 43.5 x 30 mm, weighs 0.35 kg and comes in black, white or customized colour. Fuyuan Electronic Co., Ltd produces chargers and adapters in Dongguan and Yongzhou with 450 employees and a CNAS-standard EMC laboratory. A 3-year warranty applies to every unit.

Model:
FY2942000
Brand:
Fuyuang
Code:
FY2942000


Availability:

Product Overview

The FY2942000 is a 3-pin DIN power supply lithium li-ion battery charger with a 29.4V 2A output rated 58.8W. It charges 7S lithium battery packs and is commonly used with iRobot Scooba and Roomba vacuum cleaners, e-bikes and electric golf carts. Input is 100-240V at 0.9A. Charging uses a CC-CV-floating charge profile, and protection covers short circuit, overload, over-voltage and over-temperature. The desktop-format unit measures 113 x 43.5 x 30 mm and weighs 0.35 kg.

Key Features

• 3-pin DIN power supply and 29.4V 2A lithium battery charger • 58.8W output for 7S lithium battery packs • 100-240V 0.9A universal AC input • CC-CV-Floating Charge charging mode • Short circuit, overload, over-voltage and over-temperature protection • Desktop charger format with DC output • Black, white or customized colour options • UL, cUL, GS, CE, SAA, KC, PSE, CB, FCC, RoHS and REACH certified

Technical Specifications

• Model: FY2942000 • Product type: 3-pin DIN power supply / lithium battery charger • Input: 100-240V, 0.9A • Output: 29.4V 2A • Output power: 58.8W • Battery: 7S lithium battery pack • Charge mode: CC-CV-Floating Charge • Protection: short circuit, overload, over-voltage, over-temperature • Dimension: 113 x 43.5 x 30 mm • Weight: 0.35 kg • Color: black, white or customized • Certification: UL, cUL, GS, CE, SAA, KC, PSE, CB, FCC, RoHS, REACH • Warranty: 3 years

Applications

• iRobot Scooba and Roomba vacuum cleaners • E-bikes and electric bicycles • Electric golf carts • 7S lithium battery packs • Cleaning and service robots

Customization & Service

Fuyuan Electronic Co., Ltd offers OEM and ODM services on this charger, including custom output voltage and current, custom DC/DIN connector, private labeling and LOGO printing. The in-house CNAS-standard EMC laboratory supports testing before formal certification to shorten the development cycle. Every unit is 100% factory inspected, receives 4-8 hours of full-load burn-in and carries a 3-year warranty. MOQ is 100 PCS.
