Fuyuang FY1689900 16.8V 10A 168W Li-ion Battery Charger for 4S Packs, Electric Wheelchairs and Hoverboards

Fuyuang FY1689900 16.8V 10A 168W Li-ion Battery Charger for 4S Packs, Electric Wheelchairs and Hoverboards

Name: Fuyuang FY1689900 16.8V 10A 168W Li-ion Battery Charger for 4S Packs, Electric Wheelchairs and Hoverboards
Brand: Fuyuang
Rating: 5.0 (54 reviews)

The Fuyuang FY1689900 is a 168W li-ion battery charger that delivers 16.8V 10A to 4S lithium battery packs with a 14.4V nominal voltage. It runs from a 100-240V input and is aimed at electric wheelchairs, e-bikes, hoverboards and electric scooter motors. Efficiency is above 88%. Short circuit, over-current and over-voltage protection are built in, and the unit measures 178 x 80 x 46 mm and weighs 0.78 kg, in black or white. The DC output suits charging 4S lithium battery packs. Fuyuan Electronic Co., Ltd has produced chargers and power supplies since 2005 with 450 employees and 108,000 m2 of facilities. A 3-year warranty and 100% factory inspection apply.

Model:
FY1689900
Brand:
Fuyuang
Code:
FY1689900


Availability:

Product Overview

The FY1689900 is a 168W li-ion battery charger that provides 16.8V 10A to 4S lithium battery packs at 14.4V nominal. It is designed for mobility and light electric vehicle applications such as electric wheelchairs, e-bikes, hoverboards and electric scooter motors. A 100-240V input suits mains supplies worldwide, efficiency is above 88%, and the output stage protects against short circuit, over-current and over-voltage conditions. The unit measures 178 x 80 x 46 mm and weighs 0.78 kg.

Key Features

• 16.8V 10A output charges 4S lithium battery packs (14.4V nominal) • 168W output power • 100-240V AC input • Efficiency above 88% • Short circuit, over-current and over-voltage protection • Compact 178 x 80 x 46 mm housing weighing 0.78 kg • Black or white housing options • UL, cUL, GS, CE, SAA, KC, PSE, CB, FCC, RoHS and REACH certified

Technical Specifications

• Model: FY1689900 • Product type: li-ion battery charger / power supply adapter • Input: 100-240V, 1.9A • Output: 16.8V 10A DC • Output power: 168W • Battery: 4S lithium battery pack (14.4V) • Efficiency: >88% • Protection: short circuit, over-current, over-voltage • Dimension: 178 x 80 x 46 mm • Weight: 0.78 kg • Color: black or white • Certification: UL, cUL, GS, CE, SAA, KC, PSE, CB, FCC, RoHS, REACH • Warranty: 3 years

Applications

• Electric wheelchairs • E-bikes and electric bicycles • Hoverboards • Electric scooter motors • 4S lithium battery packs

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on this charger, covering custom output voltage and current, custom DC connectors, private labeling and LOGO printing. The CNAS-standard EMC laboratory allows EMC behaviour to be validated in advance of certification testing. Every charger is 100% factory inspected, receives 4-8 hours of full-load burn-in and carries a 3-year warranty. MOQ is 100 PCS.
