Fuyuang FY5462000 54.6V 1A-10A Lithium Battery Charger 56W-560W for 48V E-bike, Robot and Scooter Packs

Fuyuang FY5462000 54.6V 1A-10A Lithium Battery Charger 56W-560W for 48V E-bike, Robot and Scooter Packs

Name: Fuyuang FY5462000 54.6V 1A-10A Lithium Battery Charger 56W-560W for 48V E-bike, Robot and Scooter Packs
Brand: Fuyuang
Rating: 5.0 (89 reviews)

The Fuyuang FY5462000 is a 48V (54.6V) lithium battery charger with output current from 1A to 10A and power ratings from 56W to 560W. It charges 36V and 48V e-bike, scooter and robot battery packs, and is available in 54.6V, 58.8V, 67.2V and 84V variations. Input is 100-240V 50/60Hz, charging efficiency is 90-95% and MTBF reaches 30,000 hours. Protection includes short circuit, over-current, over-voltage, overload, reverse polarity and automatic shutdown, with free air convection cooling and a customized DC connector. Fuyuan Electronic Co., Ltd has developed 3,000+ models from 60W to 10KW since 2005. This charger includes a 3-year warranty.

Model:
FY5462000
Brand:
Fuyuang
Code:
FY5462000


Availability:

Product Overview

The FY5462000 is a 48V lithium battery charger with a 54.6V output and current options from 1A to 10A, giving power ratings of 56W to 560W. It charges 36V and 48V e-bike, scooter and robot battery packs. The platform also covers 58.8V, 67.2V and 84V output variations. Input is 100-240V 50/60Hz, charging efficiency is 90-95%, and MTBF is 30,000 hours.

Key Features

• 54.6V (48V) output with 1A to 10A current options • Power range 56W to 560W • Also available in 58.8V, 67.2V and 84V variations • 100-240V 50/60Hz universal input • Charging efficiency 90-95%, MTBF 30,000 hours • Reverse polarity protection and automatic shutdown • Short circuit, over-current, over-voltage and overload protection • Free air convection cooling with customized DC connector

Technical Specifications

• Model: FY5462000 • Product type: lithium battery charger • Input: 100-240V, 50/60Hz • Output: 54.6V (48V) 1A-10A • Output power: 56W-560W • Battery: 48V / 36V lithium battery pack • Charging efficiency: 90-95% • MTBF: 30,000 hours • Cooling: cooling by free air convection • Protection: short circuit, over-current, over-voltage, overload, reverse polarity, automatic shutdown • DC connector: customized • Material: PC fireproof material • Function: fast charger • Warranty: 3 years

Applications

• 48V e-bikes and electric bicycles • Electric scooters and motorcycles • Robots and service robots • Food delivery and sweeping robots • 36V and 48V lithium battery packs

Customization & Service

Fuyuan Electronic Co., Ltd supports OEM and ODM projects on this charger, including custom output voltage and current, customized DC connectors, private labeling and LOGO printing. The CNAS-standard EMC laboratory allows EMC performance to be verified before formal certification. Every charger is 100% factory inspected, receives 4-8 hours of full-load burn-in and carries a 3-year warranty. MOQ is 100 PCS.
