Fuyuang FY480 250W Fanless Lithium Battery Charger 12V-60V for E-bike, Scooter, Drone and Electric Tools

Fuyuang FY480 250W Fanless Lithium Battery Charger 12V-60V for E-bike, Scooter, Drone and Electric Tools

Name: Fuyuang FY480 250W Fanless Lithium Battery Charger 12V-60V for E-bike, Scooter, Drone and Electric Tools
Brand: Fuyuang
Rating: 5.0 (5 reviews)

The Fuyuang FY480 is a 250W lithium battery charger with a 100-240Vac 50/60Hz input and a 12V-60V DC output. It covers lithium packs from 12V up to 60V, including 24V, 36V, 42V, 48V, 54.6V and 58.8V configurations. Charging follows a CC-CV-trickle or stop-charge profile with a red/green LED indicator. Cooling is fanless by free air convection, so there is no fan noise and no dust drawn into the housing. Efficiency is above 89% and the housing is fireproof PC material. Fuyuan Electronic Co., Ltd has developed more than 3,000 models from 60W to 10KW since 2005 and provides a 3-year warranty with 100% factory inspection on this charger.

Model:
FY480yyyy(y)
Brand:
Fuyuang
Code:
FY480yyyy(y)


Availability:

Product Overview

The FY480 is a 250W lithium battery charger with a 100-240Vac 50/60Hz input and a 12V-60V DC output. One platform covers 12V, 24V, 36V, 42V, 48V, 54.6V, 58.8V and 60V lithium battery packs, which makes it suitable for e-bikes, scooters, drones, electric tools and robots. Charging follows a CC-CV-trickle charge or stop-charge mode, and a red/green LED indicator shows charging status. Fanless free-air convection cooling keeps the unit quiet and free of dust ingress.

Key Features

• 250W lithium battery charger with 12V-60V DC output range • 100-240Vac 50/60Hz universal input • CC-CV-Trickle Charge / Stop Charge charging profile • Fanless design, cooled by free air convection • Efficiency above 89% • Red/green LED charging indicator • Short circuit, overload, over-voltage and over-temperature protection • Fireproof PC housing, OEM/ODM design available

Technical Specifications

• Model: FY480yyyy(y) • Product type: lithium battery charger • Input: 100-240Vac, 50/60Hz • Output: 12V-60V DC • Output power: 250W • Charge mode: CC-CV-Trickle Charge / Stop Charge • Efficiency: >89% • Cooling: fanless, free air convection • Indicator: red/green LED • Protection: short circuit, overload, over-voltage, over-temperature • Material: PC fireproof material • Size: 178 x 80 x 46 mm • Color: black • Warranty: 3 years

Applications

• E-bikes and electric bicycles • Electric scooters • Drones • Electric tools • Robots and AGV equipment

Customization & Service

Fuyuan Electronic Co., Ltd offers OEM and ODM design on this charger, including custom output voltage and current, custom DC connectors, private labeling and LOGO printing. The CNAS-standard EMC laboratory supports pre-compliance testing so certification can be reached faster. Units are 100% factory inspected, receive 4-8 hours of full-load burn-in and carry a 3-year warranty. MOQ is 10 PCS.
