Fuyuang 54.6V 2A EV Scooter Battery Charger for 48V Li-ion and LiFePO4 Packs

Fuyuang 54.6V 2A EV Scooter Battery Charger for 48V Li-ion and LiFePO4 Packs

Name: Fuyuang 54.6V 2A EV Scooter Battery Charger for 48V Li-ion and LiFePO4 Packs
Brand: Fuyuang
Rating: 5.0 (69 reviews)

The Fuyuang FY5462000 is an EV scooter battery charger rated 54.6V 2A with variants at 58.8V 2A, 58.4V 2A and 58V 2A. It takes a 100-240Vac 50-60Hz input and is used on e-scooters, e-bikes, drones, electric tools and robots, with power options from 90W to 600W. Charging follows a CC-CV-trickle profile with stop charge, and protection covers short circuit, overload, over-voltage, over-temperature, OVP, OTP, OLP and over-current. The unit is fanless, designed for no-noise operation, and built in a PC fireproof material housing with a red/green LED indicator. Manufactured by Fuyuan Electronic Co., Ltd since 2005, with 108,000 m2 of production space, a CNAS-standard EMC laboratory, 3,000+ models from 60W to 10KW, and a 3-year warranty on this product.

Model:
FY5462000
Brand:
Fuyuang
Code:
FY5462000


Availability:

Product Overview

The FY5462000 is a charger for 48V class lithium battery packs, delivering 54.6V 2A with 58.8V 2A, 58.4V 2A and 58V 2A alternatives on the same platform. Input is universal 100-240Vac at 50-60Hz. It charges e-scooters, e-bikes, drones, electric tools, robots and similar 48V to 58V systems, and works with Li-ion and LiFePO4 chemistries across 12V, 24V, 25.5V, 29.4V, 54.6V and 60V bands. Charging is CC-CV-trickle with automatic stop at full charge.

Key Features

• EV scooter charger, 54.6V 2A for 48V lithium packs • Output variants: 58.8V 2A / 58.4V 2A / 58V 2A • Charge mode: CC-CV-trickle charge with stop charge • Fanless, no-noise operation with high-speed charging • Red / green LED charge indicator • Protection: short circuit, overload, over-voltage, over-temperature, OVP, OTP, OLP, over-current • Works with Li-ion and LiFePO4 batteries • PC fireproof material housing, eco-friendly design

Technical Specifications

• Model: FY5462000 • Product name: lithium / LiFePO4 battery charger • Input: 100-240Vac, 50-60Hz • Output options: 54.6V 2A / 58.8V 2A / 58.4V 2A / 58V 2A • Power range: 90W / 120W / 150W / 200W / 450W / 600W • Charge mode: CC-CV-trickle charge / stop charge • Efficiency: above 89% • LED / LCD indicator: red / green • Battery compatibility: 12V / 24V / 25.5V / 29.4V / 54.6V / 60V lithium batteries • Protection: short circuit, overload, over-voltage, over-temperature, OVP, OTP, OLP, over-current • Certification: UL, CE, UKCA, SAA, PSE, KC • MOQ: 100 PCS

Applications

• Electric scooters • E-bikes • Drones • Electric tools • Service and industrial robots • Motorcycles

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on this platform, including custom output voltage and current, private labeling, LOGO printing and custom DC connector and AC plug selection. Engineering is supported by an in-house CNAS-standard EMC laboratory, so compliance testing can be prepared before formal certification and the development cycle can be kept short. Every unit is 100% factory inspected, receives 4-8 hours of full-load burn-in, and is covered by a 3-year warranty. Standard MOQ is 100 PCS. Fuyuan has manufactured power supplies since 2005, operates 108,000 m2 of production space in Dongguan and Yongzhou, and has developed 3,000+ models from 60W to 10KW.
