Fuyuang 4-Bank Intelligent Battery Charger 58.4V 15A 75W-1200W for 16S LiFePO4 Packs, Ebike Scooter AGV Golf Cart RV Marine

Fuyuang 4-Bank Intelligent Battery Charger 58.4V 15A 75W-1200W for 16S LiFePO4 Packs, Ebike Scooter AGV Golf Cart RV Marine

Name: Fuyuang 4-Bank Intelligent Battery Charger 58.4V 15A 75W-1200W for 16S LiFePO4 Packs, Ebike Scooter AGV Golf Cart RV Marine
Brand: Fuyuang
Rating: 5.0 (88 reviews)

The Fuyuang FY58415000 is a multi-bank intelligent charger delivering 58.4V 15A from an AC 100-240Vac 50/60Hz input. It is built for 16S LiFePO4 battery packs, and the platform also covers 14.6V 5A, 14.6V 10A, 29.2V 5A, 29.2V 10A, 43.8V 5A, 43.8V 10A, 58.4V 5A and 58.4V 10A outputs with power ratings from 75W to 1200W. Charging efficiency is 95% and the bank-based architecture lets one unit manage multiple battery banks intelligently. Cooling is by natural air convection, the housing uses ABS, aluminium alloy and PC fireproof material, and connectors include 5.5x2.5, 5.5x2.1, XLR, Anderson, alligator clip and ring terminal. Typical users include e-bikes, scooters, AGVs, AMRs, robots, golf carts, RVs and camper systems. Fuyuan Electronic Co., Ltd has built chargers since 2005, with two production bases covering 108,000 m2, 450 employees, a CNAS-standard EMC laboratory and 3,000+ models developed from 60W to 10KW. This charger carries a 3-year warranty.

Model:
FY58415000
Brand:
Fuyuang
Code:
FY58415000


Availability:

Product Overview

The FY58415000 is a 4-bank intelligent charger producing 58.4V 15A for 16S LiFePO4 battery packs. Input is AC 100-240Vac 50/60Hz, efficiency is 95%, and the platform spans 75W to 1200W. Its multi-bank architecture allows several battery banks to be charged intelligently from a single desktop unit, which suits fleet, workshop and RV environments where multiple packs are cycled every day.

Key Features

• 4-bank intelligent multi-bank charging architecture • 58.4V 15A output for 16S LiFePO4 battery packs • AC 100-240Vac 50/60Hz universal input • Platform output power from 75W to 1200W • 95% charging efficiency • Cooling by natural air convection • Connectors: 5.5x2.5, 5.5x2.1, XLR, Anderson, alligator clip, ring terminal, customisable • Housing in ABS, aluminium, aluminium alloy and PC fireproof material

Technical Specifications

• Model Number: FY58415000 • Brand: Fuyuang • Input: AC 100-240Vac 50/60Hz • Output: 58.4V 15A • Output voltage options: 14.6V 5A, 14.6V 10A, 29.2V 5A, 29.2V 10A, 43.8V 5A, 43.8V 10A, 58.4V 5A, 58.4V 10A • Output power: 75W, 120W, 150W, 200W, 300W, 400W, 600W, 800W, 1000W, 1200W • Efficiency: 95% • Type: desktop charger, fast charger • Material: ABS, aluminium, aluminium alloy, PC fireproof material • Protection: fireproof, low tension, over-charging, over-current, over-voltage, short circuit • Certification: CE, FCC, RoHS, UKCA, UL, KC, SAA, GS, ETL • Warranty: 3 years; MOQ: 100 PCS

Applications

• Electric bicycles and e-scooters • Golf carts and utility vehicles • AGV and AMR fleets • Robots and service machines • RV and camper battery systems • Industrial and medical equipment

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM work on this multi-bank charger, including bank count and layout, output voltage and current, connector type, cable length, housing, private labeling and packaging. Pre-compliance testing can be carried out in the company CNAS-standard EMC laboratory. Products are 100% factory inspected and covered by a 3-year warranty. Minimum order quantity is 100 PCS.
