Fuyuang 29.2V 2A Lithium Battery Charger for Service Robot, AGV and 24V Battery Packs

Fuyuang 29.2V 2A Lithium Battery Charger for Service Robot, AGV and 24V Battery Packs

Name: Fuyuang 29.2V 2A Lithium Battery Charger for Service Robot, AGV and 24V Battery Packs
Brand: Fuyuang
Rating: 5.0 (55 reviews)

The Fuyuang FY2922000 is a lithium battery charger for service robots, AGVs and 24V battery packs. Outputs cover 29.2V 2A, 29.4V 2A, 29V 2A, 25.2V 2A, 16.8V 2A and 12.6V 4A from a 100-240Vac 50-60Hz input, with 90W to 600W power options. Charging runs CC-CV-trickle with stop charge, and protection includes short circuit, overload, over-voltage, over-temperature, OVP, OTP, OLP and over-current. The charger is fanless and quiet for use near people, the housing is PC fireproof material, and a red/green LED shows charge state. Manufactured by Fuyuan Electronic Co., Ltd since 2005, with 108,000 m2 of production space, a CNAS-standard EMC laboratory, 3,000+ models from 60W to 10KW, and a 3-year warranty on this product.

Model:
FY2922000
Brand:
Fuyuang
Code:
FY2922000


Availability:

Product Overview

The FY2922000 is a fanless lithium battery charger for service robots, AGVs and 24V battery packs. It delivers 29.2V 2A as the base rating, with 29.4V 2A, 29V 2A, 25.2V 2A, 16.8V 2A and 12.6V 4A variants available. The charger covers 12V, 24V and 29.4V lithium systems used in robotics, drones, e-bikes, scooters and electric tools. The CC-CV-trickle profile with stop charge and the full protection set make it suitable for charging cycles that run without supervision.

Key Features

• Charger for service robots, AGV and 24V battery packs • Output options: 29.2V 2A / 29.4V 2A / 29V 2A / 25.2V 2A / 16.8V 2A / 12.6V 4A • Charge mode: CC-CV-trickle charge with stop charge • Fanless, no-noise operation with high-speed charging • Red / green LED charge indicator • Protection: short circuit, overload, over-voltage, over-temperature, OVP, OTP, OLP, over-current • PC fireproof material housing, eco-friendly design • OEM and ODM customisation available

Technical Specifications

• Model: FY2922000 • Product name: lithium / LiFePO4 battery charger • Input: 100-240Vac, 50-60Hz • Output options: 29.2V 2A / 29.4V 2A / 29V 2A / 25.2V 2A / 16.8V 2A / 12.6V 4A • Power range: 90W / 120W / 150W / 200W / 450W / 600W • Charge mode: CC-CV-trickle charge / stop charge • Efficiency: above 89% • LED / LCD indicator: red / green • Housing material: PC fireproof material • Protection: short circuit, overload, over-voltage, over-temperature • Colour: black • MOQ: 100 PCS

Applications

• Service robots • AGV and AMR fleets • Drones • E-bikes and scooters • Electric tools • Lithium battery packs for 12V to 29.4V systems

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on this platform, including custom output voltage and current, private labeling, LOGO printing and custom DC connector and AC plug selection. Engineering is supported by an in-house CNAS-standard EMC laboratory, so compliance testing can be prepared before formal certification and the development cycle can be kept short. Every unit is 100% factory inspected, receives 4-8 hours of full-load burn-in, and is covered by a 3-year warranty. Standard MOQ is 100 PCS. Fuyuan has manufactured power supplies since 2005, operates 108,000 m2 of production space in Dongguan and Yongzhou, and has developed 3,000+ models from 60W to 10KW.
