Fuyuang 29.2V 13A Fast Battery Charger 379.6W for Golf Cart Forklift Scissor Lift AGV, 24V Lead-acid AGM GEL Charger

Fuyuang 29.2V 13A Fast Battery Charger 379.6W for Golf Cart Forklift Scissor Lift AGV, 24V Lead-acid AGM GEL Charger

Name: Fuyuang 29.2V 13A Fast Battery Charger 379.6W for Golf Cart Forklift Scissor Lift AGV, 24V Lead-acid AGM GEL Charger
Brand: Fuyuang
Rating: 5.0 (3 reviews)

The Fuyuang FY2920000 is a fast desktop battery charger delivering 29.2V 13A (379.6W) from an AC 100-240Vac 50/60Hz input, designed for 24V flooded lead-acid, AGM and Gel batteries. Platform output power is 600W. Built with nine layers of charging protection, it guards against under-voltage, over-voltage, over-heating, over-current, reverse polarity and short circuit, and automatically cuts power in case of abnormal voltage. In high-temperature environments it reduces output current intelligently and shuts down when internal temperature exceeds 60C, protecting both charger and battery. A built-in temperature sensor and charging indicator support safe daily operation. Fuyuan Electronic Co., Ltd has manufactured power products since 2005, operates 108,000 m2 of production space with 450 employees, and has developed 3,000+ models from 60W to 10KW. This charger is covered by a 3-year warranty with a 50 PCS minimum order quantity.

Model:
FY2920000
Brand:
Fuyuang
Code:
FY2920000


Availability:

Product Overview

The FY2920000 is a fast desktop charger rated 29.2V 13A (379.6W) with an AC 100-240Vac 50/60Hz input and 95% charging efficiency. It is designed for 24V flooded lead-acid, AGM and Gel battery packs. It fits equipment such as scissor lifts, golf carts, sightseeing vehicles, electric forklifts, patrol vehicles, floor scrubbers and automated guided vehicles, where frequent charge cycles demand reliability.

Key Features

• 29.2V 13A (379.6W) output for 24V battery systems • AC 100-240Vac 50/60Hz universal input • Nine-layer charging protection design • Built-in temperature sensor with charging indicator • Intelligent output current reduction in high-temperature conditions and shutdown above 60C internal temperature • Automatic power cut-off if abnormal voltage is detected • Charging efficiency of 95% • Housing in ABS, aluminium alloy and PC fireproof material

Technical Specifications

• Model Number: FY2920000 • Brand: Fuyuang • Type: desktop charger, fast charger • Input: AC 100-240Vac 50/60Hz • Output: 29.2V 13A (379.6W) • Output power: 600W • Charging efficiency: 95% • Key feature: 9 charging protections, built-in temperature sensor • Function: battery charging, fast charger • Battery suitability: 24V flooded lead-acid, AGM, Gel • Material: ABS, aluminium alloy, PC fireproof material • Certification: UL, GS, CE, RoHS, REACH, SAA, PSE • Warranty: 3 years; MOQ: 50 PCS

Applications

• Golf carts and sightseeing vehicles • Electric forklifts • Scissor lifts and aerial work platforms • Automated guided vehicles • Floor scrubbers • Patrol vehicles and industrial fleet equipment

Customization & Service

OEM and ODM services are available on this charger, covering custom charging profile, output current, connector type, cable assembly, housing and packaging. The company CNAS-standard EMC laboratory supports pre-compliance testing so certification can be prepared earlier in the project. Every unit is 100% factory inspected and covered by a 3-year warranty. Minimum order quantity is 50 PCS.
