Fuyuang 14.6V 5A LiFePO4 Battery Charger 12V-126V 2A-50A Platform for E-bike, Scooter and Robot

Fuyuang 14.6V 5A LiFePO4 Battery Charger 12V-126V 2A-50A Platform for E-bike, Scooter and Robot

Name: Fuyuang 14.6V 5A LiFePO4 Battery Charger 12V-126V 2A-50A Platform for E-bike, Scooter and Robot
Brand: Fuyuang
Rating: 5.0 (9 reviews)

The FY2946000 is a desktop LiFePO4 battery charger rated 14.6V 5A for 4S 12V packs. The same platform scales across 12V, 24V, 36V, 48V, 60V, 72V, 84V and 126V battery systems with current options from 2A to 50A, so a single mechanical design serves everything from small 12V packs to large traction batteries. It runs from a 100-240Vac 50/60Hz input and charges with a CC-CV-trickle profile with stop charge. Over-voltage, over-current, overload, over-temperature and short-circuit protection are built in, and free-air convection cooling keeps the charger quiet without a fan. The housing is PC fireproof material and a red/green LED shows charge status. Fuyuan Electronic Co., Ltd has manufactured power products since 2005, with 108,000 m2 of production space, a CNAS-standard EMC laboratory, 3,000+ developed models from 60W to 10KW, and a 3-year warranty on this charger.

Model:
FY2946000
Brand:
Fuyuang
Code:
FY2946000


Availability:

Product Overview

The FY2946000 is a desktop LiFePO4 battery charger rated 14.6V 5A for 4S 12V packs. The platform covers 12V to 126V systems with 2A to 50A output options, allowing the same enclosure design to serve small packs and large traction batteries. It accepts 100-240Vac 50/60Hz input and charges with a CC-CV-trickle profile with automatic stop. Typical applications are e-bikes, scooters, robots, AGVs and industrial battery packs.

Key Features

• 14.6V 5A output for 4S LiFePO4 and lithium packs • Platform spans 12V to 126V battery voltages • Current options from 2A to 50A across the platform • Universal 100-240Vac 50/60Hz input • CC-CV-trickle charge mode with stop charge • Fanless cooling by free air convection, no noise • Over-voltage, over-current, overload, over-temperature and short-circuit protection • PC fireproof housing with red/green LED indicator

Technical Specifications

• Model: FY2946000 • Input: 100-240Vac, 50/60Hz • Output: 14.6V 5A • Platform voltage coverage: 12V / 24V / 36V / 48V / 60V / 72V / 84V / 126V • Platform current range: 2A to 50A • Platform power: 90W / 120W / 150W / 200W / 450W / 600W • Battery compatibility: LiFePO4, lithium-ion, lead-acid • Charge mode: CC-CV-Trickle Charge, stop charge • Charging efficiency: above 89% • Housing: PC fireproof material, black • Certification: UL, cUL, FCC, CE, GS, CB, UKCA, KC, PSE, SAA, CCC, NOM, RoHS, REACH • MOQ: 100 PCS

Applications

• E-bikes and scooters • Robots and AGV equipment • Electric tools • Drones • Industrial battery packs • Energy storage systems

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on this platform, including custom output voltage and current, custom DC connectors and AC plugs, private labeling, LOGO printing and custom packaging. Pre-compliance testing is available through the CNAS-standard EMC laboratory to support certification planning. Every unit is covered by a 3-year warranty and receives 4-8 hours of full-load burn-in plus 100% factory inspection. Standard MOQ is 100 PCS.
