Fuyuang 14.6V 20A LiFePO4 Battery Charger 400W-1200W for Industrial Robotics, AGV, AMR, Golf Cart, RV and Marine

Fuyuang 14.6V 20A LiFePO4 Battery Charger 400W-1200W for Industrial Robotics, AGV, AMR, Golf Cart, RV and Marine

Name: Fuyuang 14.6V 20A LiFePO4 Battery Charger 400W-1200W for Industrial Robotics, AGV, AMR, Golf Cart, RV and Marine
Brand: Fuyuang
Rating: 5.0 (8 reviews)

The Fuyuang FY14620000 is a high-current desktop battery charger rated 14.6V 20A for large LiFePO4, lithium and lead-acid battery banks used in industrial vehicles, golf carts, RVs, marine equipment and robotics. Input is 100-240V 50/60Hz and the platform covers 400W, 600W and 1200W power levels. With 95% efficiency, the charger runs cool and is cooled by free air convection with zero noise. It protects against over-charging, over-current, over-voltage and short circuit, and an LED indicator shows charging status. Output variants include 14.6V 10A / 20A, 25.5V 10A / 20A, 29.2V 20A and 58.4V 10A / 20A. Manufactured by Fuyuan Electronic Co., Ltd since 2005, with 108,000 m2 of production space, 450 employees, a CNAS-standard EMC laboratory, 3,000+ developed models from 60W to 10KW, and a 3-year warranty on this product.

Model:
FY14620000
Brand:
Fuyuang
Code:
FY14620000


Availability:

Product Overview

The FY14620000 is an industrial-grade charger delivering 14.6V 20A for LiFePO4, lithium-ion and lead-acid batteries. Typical users are AGVs, AMRs, golf carts, RVs, electric vehicles, marine equipment and industrial cleaning machines. The unit combines high current output with 95% efficiency and fanless cooling, so it stays quiet and needs minimal maintenance. Output voltage and current can be tailored to the battery bank, and an LED indicator reports charging status.

Key Features

• High current 14.6V 20A output for fast charging of large battery banks • 95% charging efficiency with low heat generation • Fanless cooling design with zero noise • Protection: short circuit, over-voltage, over-current and over-charging • LED charging indicator built in • Isolated input and output design in flame-retardant ABS, aluminium alloy and fireproof PC • Output variants: 14.6V 10A / 14.6V 20A / 29.2V 20A / 58.4V 10A / 58.4V 20A / 25.5V 10A / 25.5V 20A • 3-year warranty with 4-8 hours full-load burn-in

Technical Specifications

• Model: FY14620000 • Product: 14.6V 20A LiFePO4 / lithium / lead-acid battery charger • Input: 100-240V 50-60Hz • Output: 14.6V 10A / 14.6V 20A / 29.2V 20A / 58.4V 10A / 58.4V 20A / 25.5V 10A / 25.5V 20A • Power range: 400W / 600W / 1200W • Charging efficiency: 95% • Protection: short circuit, over-voltage, over-current, over-charging • Housing material: ABS, aluminium, aluminium alloy, fireproof PC • Type: desktop charger with LED indicator • Certification: UL, CE, GS, ETL, SAA, KC, FCC, PSE, RoHS, REACH, UKCA, KCC • MOQ: 100 PCS

Applications

• AGV and AMR automated guided vehicles • Golf carts and electric vehicles • RVs and marine equipment • Robotics and industrial automation • Industrial cleaning and floor-care machines • Energy storage and backup battery banks

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on this platform, covering custom output voltage and current, charging profiles, DC connectors, AC plugs, cable length, housing colour, private labeling, LOGO printing and packaging. Engineering work is supported by a CNAS-standard EMC laboratory, so compliance testing can be prepared before formal certification and the development cycle shortened; custom projects can reach engineering completion in as little as 10 days. Every unit is covered by a 3-year warranty, is 100% factory inspected and receives 4-8 hours of full-load burn-in. Standard MOQ for this item is 100 PCS. Certifications held on this platform include UL, CE, GS, ETL, SAA, KC, FCC, PSE, RoHS, REACH, UKCA and KCC.
