Fuyuang 12.6V-126V 1-40A Adjustable Battery Charger for LiFePO4, Lithium and Lead-acid Packs

Fuyuang 12.6V-126V 1-40A Adjustable Battery Charger for LiFePO4, Lithium and Lead-acid Packs

Name: Fuyuang 12.6V-126V 1-40A Adjustable Battery Charger for LiFePO4, Lithium and Lead-acid Packs
Brand: Fuyuang
Rating: 5.0 (10 reviews)

The Fuyuang FY2940000 is a customisable battery charger covering 12.6V, 14.6V, 16.8V, 29.2V, 29.4V, 54.6V, 58.4V, 73V and 84V outputs with currents from 1A to 40A. It runs from a 100-240Vac 50/60Hz input and is used across e-bikes, scooters, robotics, drones, AGVs and golf carts. Output rails include 12.6V, 16.8V, 29.4V, 42V, 54.6V and 14.6V at 1-20A, 73V at 1-15A, 84V at 1-12A and 126V at 1-8A. Charging is high speed at 95% efficiency with full protection against over-voltage, over-current, short circuit and over-heating, and the unit is fanless for quiet operation. Manufactured by Fuyuan Electronic Co., Ltd since 2005, with 108,000 m2 of production space, a CNAS-standard EMC laboratory, 3,000+ models from 60W to 10KW, and a 3-year warranty on this product.

Model:
FY2940000
Brand:
Fuyuang
Code:
FY2940000


Availability:

Product Overview

The FY2940000 is an adjustable battery charger and power supply adapter for 12V to 84V battery systems. Output voltage can be set across 12.6V to 126V and current from 1A to 40A, with power levels from 60W to 600W and full customisation to order. It serves electric vehicles, e-bikes, scooters, robotics, drones, AGVs and golf carts, and works with LiFePO4, lithium, lithium-ion and lead-acid packs. Engineering support covers custom voltage and current, custom connectors and plugs, and custom packaging.

Key Features

• Adjustable output: 12.6V to 126V, 1A to 40A • Rails include 12.6V / 14.6V / 16.8V / 29.2V / 29.4V / 54.6V / 58.4V / 73V / 84V • High speed charging at 95% efficiency • Full protection against over-voltage, over-current, short circuit and over-heating • Fanless design, cooling by natural air convection, quiet cooling below 35dB • Supports LiFePO4, lithium, lithium-ion and lead-acid chemistries • Custom voltage, current, connectors, plugs and packaging • Low MOQ for trial orders

Technical Specifications

• Model: FY2940000 • Type: power supply charger / adapter • Input: 100-240Vac, 50/60Hz • Output: 12.6V / 14.6V / 16.8V / 29.2V / 29.4V / 54.6V / 58.4V / 73V / 84V (1-40A) • Output rails: 12.6V 1-20A / 16.8V 1-20A / 29.4V 1-20A / 42V 1-20A / 54.6V 1-20A / 14.6V 1-20A / 73V 1-15A / 84V 1-12A / 126V 1-8A • Power range: 60W / 80W / 120W / 150W / 200W / 300W / 350W / 400W / 600W • Charging efficiency: 95% • Battery compatibility: 12V / 24V / 25.5V / 29.4V / 54.6V / 58.4V / 60V / 72V / 84V lithium batteries • Housing material: ABS, aluminium alloy, PC fireproof material • Protection: fireproof, low tension, over-charging, over-current, over-voltage, short circuit • Certification: UL, CE, GS, ETL, SAA, KC, FCC, PSE, RoHS, REACH, UKCA, KCC • MOQ: 10 PCS

Applications

• Electric vehicles, e-bikes and scooters • Robotics, AGV and AMR • Drones • Golf carts • Electric tools • Industrial and medical devices • Household electrical appliances • Home security systems

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on this platform, including custom output voltage and current, private labeling, LOGO printing and custom DC connector and AC plug selection. Engineering is supported by an in-house CNAS-standard EMC laboratory, so compliance testing can be prepared before formal certification and the development cycle can be kept short. Every unit is 100% factory inspected, receives 4-8 hours of full-load burn-in, and is covered by a 3-year warranty. Standard MOQ is 100 PCS. Fuyuan has manufactured power supplies since 2005, operates 108,000 m2 of production space in Dongguan and Yongzhou, and has developed 3,000+ models from 60W to 10KW.
