Fuyuang FY5883000 176.4W 58.8V 3A E-bike Battery Charger for 52V 14S Li-ion Packs

Fuyuang FY5883000 176.4W 58.8V 3A E-bike Battery Charger for 52V 14S Li-ion Packs

Name: Fuyuang FY5883000 176.4W 58.8V 3A E-bike Battery Charger for 52V 14S Li-ion Packs
Brand: Fuyuang
Rating: 5.0 (95 reviews)

The Fuyuang FY5883000 is a 176.4W e-bike battery charger rated 58.8V 3A for 52V 14S Li-ion packs. It takes a 100-240VAC 50-60Hz input and charges with a CC-CV-floating profile that shuts off at end of charge, using a fanless design cooled by free air convection for quiet running. The case is a 94-V0 fireproof plastic enclosure measuring 178*80*46mm and weighing 0.80KG, with a red / green LED indicator showing charge progress. Fuses are fitted on both the input and the output, and every unit receives a 4-hour full-load aging test. Reverse polarity, timing, anti-spark and pre-charge protection are available as options. The charger is manufactured by Fuyuan Electronic Co., Ltd (Fuyuang), a power supply manufacturer founded in 2005 with two production bases in Dongguan and Yongzhou, 108,000 m2 of factory space and 450 employees. More than 3,000 models have been developed across a 60W to 10KW range, and every unit ships with a 3-year warranty.

Model:
FY5883000
Brand:
Fuyuang
Code:
FY5883000


Availability:

Product Overview

The FY5883000 is a 176.4W charger delivering 58.8V 3A to 52V 14S Li-ion e-bike packs. It runs from 100-240VAC 50-60Hz, uses CC-CV-floating charging with shut-off at end of charge, and is cooled by free air convection without a fan. The 94-V0 fireproof plastic case measures 178*80*46mm at 0.80KG, carries a red / green LED indicator and fuses on both input and output, and each unit passes a 4-hour full-load aging test before shipment.

Key Features

• 176.4W power stage with 58.8V 3A output for 52V 14S Li-ion e-bike packs • Fanless design cooled by free air convection, giving quiet operation • Charging mode CC-CV-floating charge with shut-off at end of charge • LED indicator: red means charging, green means charging is complete • 94-V0 fireproof plastic case, 178*80*46mm, 0.80KG • Fuses installed on both input and output for double safety • 4-hour full-load aging test on every unit • Optional reverse polarity, timing, anti-spark and pre-charge protection

Technical Specifications

• Model: FY5883000 • Input: 100-240VAC, 50-60Hz • Output: 58.8V 3A • Output power: 176.4W • Efficiency: 90% • Charging mode: CC-CV-floating charging / shut off • Cooling: fanless design, cooling by free air • Dimensions: 178*80*46mm • Weight: 0.80KG • Housing material: PC fireproof material, 94-V0 fireproof plastic case • Certification: UL, FCC, CB, CE, GS, UKCA, PSE, SAA, RCM, KC, KCC, CCC, RoHS, REACH • MOQ: 100 PCS

Applications

• E-bikes • Electric scooters • Robots • Drones • Portable power stations • Electric wheelchairs • Cleaning robots • Humanoid robots

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on the FY5883000 platform. Output voltage and current, AC and DC connectors, cable length, housing, labelling and LOGO printing can all be customized. Engineering work is supported by a CNAS-standard EMC laboratory and an in-house RoHS testing room, so compliance can be screened before formal certification and custom development can be completed in as little as 10 days. This is a private-mould design. Every unit is 100% factory inspected, receives 4-8 hours of full-load burn-in, and is covered by a 3-year warranty. Standard MOQ is 100 PCS. Certifications available for this platform: UL, FCC, CB, CE, GS, UKCA, PSE, SAA, RCM, KC, KCC, CCC, RoHS, REACH.
