Fuyuang FY54607000 54.6V 7A 13S Li-ion Battery Charger with CAN Bus for 48V Electric Scooter, AGV and Industrial Packs

Fuyuang FY54607000 54.6V 7A 13S Li-ion Battery Charger with CAN Bus for 48V Electric Scooter, AGV and Industrial Packs

Name: Fuyuang FY54607000 54.6V 7A 13S Li-ion Battery Charger with CAN Bus for 48V Electric Scooter, AGV and Industrial Packs
Brand: Fuyuang
Rating: 5.0 (31 reviews)

The Fuyuang FY54607000 is a 54.6V 7A charger for 13S 48V lithium-ion packs, built with CAN bus protocol so that charging status and battery data can be read by a vehicle or fleet controller instead of only by an LED. It weighs 2.5kg and accepts a 100-240V 0.2A input. The charger is designed for high duty cycles: electric scooters, AGVs, industrial equipment, medical devices and e-bike fleets that need a 7A charging current. Protection covers short circuit, over-voltage, over-current, over-charging, over-temperature and low tension, and the housing combines PC fireproof material with aluminium and ABS options for thermal performance. Fuyuan Electronic Co., Ltd has manufactured chargers since 2005, with 108,000 m2 of production space, 450 employees and 3,000+ developed models from 60W to 10KW. This charger carries a 3-year warranty.

Model:
FY54607000
Brand:
Fuyuang
Code:
FY54607000


Availability:

Product Overview

The FY54607000 charges 13S 48V lithium-ion battery packs at 54.6V 7A, a current level that shortens charging time on scooters, AGVs and industrial vehicles. CAN bus protocol support allows the charger to exchange data with a host controller for fleet management or service diagnostics. A 100-240V 0.2A input and a 2.5kg chassis with aluminium and PC fireproof housing options make the unit suitable for both mobile and fixed installations.

Key Features

• 54.6V 7A output for 13S 48V lithium-ion packs • CAN bus protocol for charging data and fleet integration • Fast charging speed for high duty-cycle vehicles • 100-240V / 0.2A wide range AC input • Aluminium, ABS and PC fireproof housing options • Short circuit, over-voltage and over-current protection • OVP, OTP, OLP, low tension, over-charging and fireproof protection logic • Custom logo, custom connector, customer-specified plug and packaging

Technical Specifications

• Model: FY54607000 • Input: 100-240V / 0.2A • Output: 54.6V 7A • Battery: 13S 48V lithium-ion pack • Communication: CAN bus protocol • Power options: 60W / 90W / 100W / 120W / 125W / 135W / 140W / 150W / 200W / 400W • Weight: 2.5KG • Material: PC fireproof, ABS, aluminium alloy and aluminium options • Connector: customers' requirements • Protection: short circuit, OVV, OVC, OVP, OTP, OLP, low tension, over-charging, fireproof • Certification: CE, FCC, RoHS, UKCA, UL • MOQ: 100 PCS

Applications

• Electric scooters and mopeds • AGVs and autonomous mobile robots • Industrial equipment and machinery • Electric tool and battery pack fleets • Medical devices and mobility equipment • Home security systems and household appliances

Customization & Service

The model is produced in a private mold and accepts customised logo, connectors, plugs, cable and packaging, along with private labeling. CAN 2.0 / RS485 communication is available for remote monitoring and real-time data integration, and protection logic can be configured to the application. Fuyuan Electronic Co., Ltd validates designs in a CNAS-standard EMC laboratory before certification and 100% inspects every charger with full-load burn-in. The product carries a 3-year warranty. Standard MOQ is 100 PCS.
