Fuyuang FY480 Series 450W Fanless Lithium Battery Charger 12V-60V for E-bikes, Scooters, Drones and Robots

Fuyuang FY480 Series 450W Fanless Lithium Battery Charger 12V-60V for E-bikes, Scooters, Drones and Robots

Name: Fuyuang FY480 Series 450W Fanless Lithium Battery Charger 12V-60V for E-bikes, Scooters, Drones and Robots
Brand: Fuyuang
Rating: 5.0 (93 reviews)

The Fuyuang FY480 series is a 450W lithium battery charger that covers a 12V to 60V output range, making one model family usable across e-bikes, scooters, drones, electric tools and robots. It accepts a 100-240VAC 50-60Hz universal input and charges with a CC-CV-Trickle sequence that stops at full charge. Cooling is by free air convection with a fanless design, so the charger runs quietly and needs no fan service. The PC fireproof material housing measures 233*108*64mm, and short circuit, overload, over-voltage and over-temperature protection are built in. A red / green LED indicator reports charge status at a glance. The charger is manufactured by Fuyuan Electronic Co., Ltd (Fuyuang), a power supply manufacturer founded in 2005 with two production bases in Dongguan and Yongzhou, 108,000 m2 of factory space and 450 employees. More than 3,000 models have been developed across a 60W to 10KW range, and every unit ships with a 3-year warranty.

Model:
FY480yyyy(y)
Brand:
Fuyuang
Code:
FY480yyyy(y)


Availability:

Product Overview

The FY480 series is a 450W fanless lithium battery charger platform with a 12V-60V output range, charged from a 100-240VAC 50-60Hz input. One platform covers e-bikes, scooters, drones, electric tools and robots. The CC-CV-Trickle charge mode ends with a stop-charge function, and the fanless PC fireproof housing measures 233*108*64mm with a red / green LED status indicator.

Key Features

• 450W power stage covering a 12V-60V output range from one charger platform • Fanless design cooled by free air convection, with no fan maintenance • CC-CV-Trickle charge mode with stop-charge function • Efficiency above 89% • Short circuit, overload, over-voltage and over-temperature protection • PC fireproof material housing, 233*108*64mm, black • Red / green LED indicator for charging and full-charge status • OEM / ODM design with customizable output, connector and branding

Technical Specifications

• Model: FY480yyyy(y) • Input: 100-240VAC, 50-60Hz • Output: 12V-60V (customizable) • Output power: 450W • Charge mode: CC-CV-Trickle charge / stop charge • Efficiency: >89% • Protection: short circuit, overload, over-voltage, over-temperature • Cooling: fanless, free air convection • Dimensions: 233*108*64mm • Housing material: PC fireproof material, black • LED / LCD indicator: red / green • MOQ: 10 PCS

Applications

• E-bikes • Electric scooters • Drones • Electric tools • Robots • 12V-60V lithium battery packs

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on the FY480yyyy(y) platform. Output voltage and current, AC and DC connectors, cable length, housing, labelling and LOGO printing can all be customized. Engineering work is supported by a CNAS-standard EMC laboratory and an in-house RoHS testing room, so compliance can be screened before formal certification and custom development can be completed in as little as 10 days. Every unit is 100% factory inspected, receives 4-8 hours of full-load burn-in, and is covered by a 3-year warranty. Standard MOQ is 10 PCS. Certifications are available per destination on request.
