Fuyuang FY4204000 42V 4A 168W Li-ion Battery Charger for 36V E-bike, E-scooter, Cleaning Robot and Electric Wheelchair

Fuyuang FY4204000 42V 4A 168W Li-ion Battery Charger for 36V E-bike, E-scooter, Cleaning Robot and Electric Wheelchair

Name: Fuyuang FY4204000 42V 4A 168W Li-ion Battery Charger for 36V E-bike, E-scooter, Cleaning Robot and Electric Wheelchair
Brand: Fuyuang
Rating: 5.0 (50 reviews)

The Fuyuang FY4204000 delivers 42V 4A (168W) for 36V lithium-ion battery packs, making it a practical charger for e-bikes, e-scooters, cleaning robots, electric wheelchairs and portable power stations. Input is 100-240VAC 50-60Hz and charging efficiency is 90%. Charging uses a CC-CV floating profile that ends with a shut-off, so the pack is left in a safe state. Protection covers short circuit, overload, over-voltage, over-temperature, over-charging and low tension, and the LED indicator shows charging progress. The fanless design cools by free air convection inside a 178*80*46MM PC fireproof housing weighing 0.80kg. Fuyuan Electronic Co., Ltd has manufactured chargers since 2005 and runs 108,000 m2 of production space with a CNAS-standard EMC laboratory. Certification routes include UL, FCC, CE, GS, UKCA, PSE, SAA, RCM, KC, KCC, CCC, RoHS and REACH, and the product carries a 3-year warranty.

Model:
FY4204000
Brand:
Fuyuang
Code:
FY4204000


Availability:

Product Overview

The FY4204000 is a 42V 4A charger for 10S 36V lithium-ion packs, rated 168W. It is used on e-bikes, e-scooters, cleaning robots, electric wheelchairs, portable power stations and motorcycle battery packs. The charger accepts 100-240VAC 50-60Hz and uses a CC-CV floating charge mode with shut-off, which brings the pack to full charge and then stops charging to protect cycle life.

Key Features

• 42V 4A output for 36V lithium-ion battery packs • 168W output power with 90% charging efficiency • 100-240VAC / 50-60Hz universal AC input • Charging mode: CC-CV floating charging with shut off • Fanless design, cooling by free air, quiet operation • Short circuit, overload, over-voltage and over-temperature protection • Over-charging, overvoltage and low tension protection logic • LED indicator and PC fireproof housing, 0.80kgs

Technical Specifications

• Model: FY4204000 • Product name: 42V 4A 36V lithium battery e-scooter and e-bike charger • Input: 100-240VAC / 50-60HZ • Output: 42V 4A • Output power: 168W • Efficiency: 90% • Charging mode: CC-CV floating charging / shut off • Dimension: 178*80*46MM, weight 0.80kgs • Indicator: LED, DC output port • Protection: short circuit, OLP, over-charging, overvoltage, over temperature, overload • Certification: UL, FCC, CE, GS, UKCA, PSE, SAA, RCM, KC, KCC, CCC, RoHS, REACH • MOQ: 100 PCS

Applications

• Electric bicycles and e-bike packs • Electric scooters and e-scooters • Cleaning robots and service robots • Electric wheelchairs and power wheels • Humanoid and mobile robots • Portable power stations and battery packs

Customization & Service

This charger is produced in a private mold and supports modified and customised designs: output voltage and current, DC connector, cable length, housing colour, private labeling, LOGO printing and packaging. Fuses are installed at both the input and output for double safety, and optional features include reverse-polarity protection, timing protection, anti-spark, pre-charging and automatic shut-off. Every charger is aged at full load for 4 hours, 100% factory inspected and covered by a 3-year warranty. Standard MOQ is 100 PCS.
