Fuyuang FY1265000 Class 2 12.6V 5A Lithium Battery Charger 63W for 12V Li-ion Packs, E-bike and Medical Equipment

Fuyuang FY1265000 Class 2 12.6V 5A Lithium Battery Charger 63W for 12V Li-ion Packs, E-bike and Medical Equipment

Name: Fuyuang FY1265000 Class 2 12.6V 5A Lithium Battery Charger 63W for 12V Li-ion Packs, E-bike and Medical Equipment
Brand: Fuyuang
Rating: 5.0 (48 reviews)

The Fuyuang FY1265000 is a Class 2 lithium battery charger designed to charge 12V lithium battery packs. With a 100-240V 50/60Hz input and a 12.6V 5A output, it delivers 63W and suits 12V 10Ah to 20Ah lithium packs. Efficiency is above 89%. Short circuit, overload, over-voltage and over-temperature protection keep charging safe, and the charger measures 133 x 58 x 31 mm in a black, white or customized housing. Typical applications include battery packs, electric vehicles, robot scooters, medical equipment and e-bikes. Fuyuan Electronic Co., Ltd has been a power supply manufacturer since 2005, with 108,000 m2 of production capacity and 450 employees. Every unit is 100% factory inspected and carries a 3-year warranty.

Model:
FY1265000
Brand:
Fuyuang
Code:
FY1265000


Availability:

Product Overview

The FY1265000 is a Class 2 lithium battery charger that takes 100-240V 50/60Hz AC input and delivers 12.6V 5A to 12V lithium battery packs. Output power is 63W, which suits 12V 10Ah, 12Ah, 17Ah and 20Ah lithium batteries. Efficiency above 89% keeps charging losses low, while short circuit, overload, over-voltage and over-temperature protection guard the battery and the charger. The compact housing measures 133 x 58 x 31 mm.

Key Features

• Class 2 lithium battery charger for 12V lithium packs • 100-240V 50/60Hz universal AC input • 12.6V 5A DC output, 63W • Efficiency above 89% • Short circuit, overload, over-voltage and over-temperature protection • Housing available in black, white or customized colour • Compact 133 x 58 x 31 mm design • UL, cUL, GS, CE, SAA, KC, PSE, CB, FCC, RoHS and REACH certified

Technical Specifications

• Model: FY1265000 • Product type: Class 2 lithium battery charger • Input: 100-240V, 50/60Hz (0.9A) • Output: 12.6V 5A • Output power: 63W • Battery: 12V lithium battery pack • Efficiency: >89% • Protection: short circuit, overload, over-voltage, over-temperature • Dimension: 133 x 58 x 31 mm • Color: black, white or customized • Certification: UL, cUL, GS, CE, SAA, KC, PSE, CB, FCC, RoHS, REACH • Warranty: 3 years

Applications

• 12V lithium battery packs (10Ah-20Ah) • Electric vehicles and e-bikes • Robot scooters • Medical equipment • Security and monitoring devices

Customization & Service

Fuyuan Electronic Co., Ltd offers OEM and ODM services for this charging platform: custom output voltage and current, custom DC connector, private labeling and LOGO printing. The in-house CNAS-standard EMC laboratory allows EMC performance to be validated before certification testing, shortening the development cycle. Each charger is 100% factory inspected and covered by a 3-year warranty. MOQ is 100 PCS.
