Fuyuang Custom 60W-900W Lithium Battery Charger 12V-54.6V 1A-20A for Robot, Scooter, E-bike and Battery Packs, OEM/ODM

Fuyuang Custom 60W-900W Lithium Battery Charger 12V-54.6V 1A-20A for Robot, Scooter, E-bike and Battery Packs, OEM/ODM

Name: Fuyuang Custom 60W-900W Lithium Battery Charger 12V-54.6V 1A-20A for Robot, Scooter, E-bike and Battery Packs, OEM/ODM
Brand: Fuyuang
Rating: 5.0 (34 reviews)

This Fuyuang custom charger platform spans 60W to 900W and output voltages of 14.6V, 16.8V, 29V, 42V and 54.6V, with charge current from 1A to 20A. It is built to order from a 100-240V 50/60Hz input, which makes it suitable for buyers who need one charger specification matched to an existing battery pack. The charging mode is CC-CV with trickle and cut-off, so the pack is charged at constant current, held at constant voltage and then disconnected to prevent overcharging. Short circuit, over-voltage, over-temperature and overload protection are standard, along with an AC/DC connector chosen to the customer requirement and a red / green LED status indicator. Fuyuan Electronic Co., Ltd has manufactured chargers since 2005, with 108,000 m2 of production space, 450 employees and 3,000+ developed models from 60W to 10KW. Designs are screened in a CNAS-standard EMC laboratory and the product carries a 3-year warranty.

Model:
FYxxxyyyyy
Brand:
Fuyuang
Code:
FYxxxyyyyy


Availability:

Product Overview

This FYxxxyyyyy platform is a custom lithium battery charger with a 60W to 900W power range and outputs of 14.6V, 16.8V, 29V, 42V and 54.6V at 1A to 20A. Buyers specify the voltage, current and connector that match their pack, and the charger is built on the same proven enclosure and control platform. It suits battery packs on robots, scooters, e-bikes, power tools and industrial equipment where a catalogue charger does not fit.

Key Features

• Custom power range from 60W to 900W • Output voltages of 14.6V, 16.8V, 29V, 42V and 54.6V • Charge current from 1A to 20A, set to your pack capacity • 100-240V 50-60Hz universal AC input • CC-CV-TC charging mode with cut-off • Efficiency of 90% minimum • Short circuit, over-voltage, over-temperature and overload protection • Red / green LED indicator and AC/DC connector to your requirement

Technical Specifications

• Model: FYxxxyyyyy • Product name: 60W-600W battery charger • Input: 100-240V / 50-60Hz • Output voltages: 14.6V / 16.8V / 29V / 42V / 54.6V • Output current: 1A to 20A, custom • Output power: 60W-900W, custom • Charging mode: CC-CV-TC / cut off • Efficiency: 90% minimum • LED / LCD indicator: red / green • AC/DC connector: according to your need • Package: small box + carton • Certification: UL, cUL, GS, CE, BS, SAA, KC, PSE, CB, FCC, EMC, RoHS, REACH • MOQ: 100 PCS

Applications

• Service, cleaning and delivery robots • Electric scooters and e-bikes • Battery pack assembly and OEM equipment • Electric power tools and garden equipment • Medical and industrial devices • Portable power stations and energy storage

Customization & Service

This is a configurable platform: output voltage, output current, AC and DC connectors, cable length, housing, indicator behaviour, private labeling, LOGO printing and packaging are all defined by the project. OEM and ODM support is standard, and optional protection features include reverse-polarity, timing, anti-spark, pre-charging and automatic shut-off. Every unit is 100% factory inspected with full-load burn-in and covered by a 3-year warranty. Standard MOQ is 100 PCS.
