Fuyuang 63V 4A 4.5A Lithium Charger for 54V 15S Li-ion E-bike and Mobility Scooter

Fuyuang 63V 4A 4.5A Lithium Charger for 54V 15S Li-ion E-bike and Mobility Scooter

Name: Fuyuang 63V 4A 4.5A Lithium Charger for 54V 15S Li-ion E-bike and Mobility Scooter
Brand: Fuyuang
Rating: 5.0 (16 reviews)

The Fuyuang FY63004000 is a 63V lithium charger for 54V 15S Li-ion packs, offered at 4A and 4.5A output with a 252W power rating. It measures 210 x 108 x 55mm and weighs 1.30kg, takes a 100-240V 50-60Hz input, and is used on e-bikes, mobility scooters, robotics and battery packs. The charge mode is CC-CV-float with cut off, and protection covers short circuit, overload, over-voltage, over-temperature, reverse polarity, timing, automatic shut-off, pre-charge and CC-CN mode with an automatic identification circuit. With 92% efficiency and a fanless plastic case, it is quiet and simple to install. Manufactured by Fuyuan Electronic Co., Ltd since 2005, with 108,000 m2 of production space, a CNAS-standard EMC laboratory, 3,000+ models from 60W to 10KW, and a 3-year warranty on this product.

Model:
FY63004000
Brand:
Fuyuang
Code:
FY63004000


Availability:

Product Overview

The FY63004000 is a lithium battery charger for 54V 15S Li-ion battery packs. It delivers 63V at 4A or 4.5A, 252W, from a 100-240V 50-60Hz input, in a compact 210 x 108 x 55mm case weighing 1.30kg. It is aimed at e-bikes, mobility scooters, robotics and battery pack assemblies. Charging runs a CC-CV-float profile with cut off, and the automatic identification circuit plus pre-charge mode help protect deeply discharged packs.

Key Features

• 63V output at 4A or 4.5A, 252W, for 15S 54V Li-ion packs • Charge mode: CC-CV-float charge with cut off • 92% efficiency with fanless, no-noise operation • Automatic identification circuit and pre-charge mode • Protection: over load, over voltage, over temperature, short circuit, reverse polarity • Timing and automatic shut-off functions • Compact plastic case, 210 x 108 x 55mm, 1.30kg per piece • Colour black or customised

Technical Specifications

• Model: FY63004000 • Product name: 63V 4A 4.5A lithium charger for 54V 15S Li-ion battery • Input: 100-240V, 50-60Hz • Output options: 63V 4A / 63V 4.5A • Power: 252W • Efficiency: 92% • Charge mode: CC-CV-float charge / cut off • Size: 210 x 108 x 55mm • Weight: 1.30kg per piece • Housing material: PC fireproof material, plastic case • Protection: short circuit, overload, over voltage, over temperature, reverse polarity • Certification: UL, FCC, CE, RoHS, CB, GS, UKCA, SAA, RCM, PSE, KC, CCC • MOQ: 100 PCS

Applications

• E-bikes • Mobility scooters • Robotics and AGV • Lithium battery packs • Electric tools • Industrial battery systems

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on this platform, including custom output voltage and current, private labeling, LOGO printing and custom DC connector and AC plug selection. Engineering is supported by an in-house CNAS-standard EMC laboratory, so compliance testing can be prepared before formal certification and the development cycle can be kept short. Every unit is 100% factory inspected, receives 4-8 hours of full-load burn-in, and is covered by a 3-year warranty. Standard MOQ is 100 PCS. Fuyuan has manufactured power supplies since 2005, operates 108,000 m2 of production space in Dongguan and Yongzhou, and has developed 3,000+ models from 60W to 10KW.
