Fuyuang 54.6V 3A 13S Smart Li-ion Battery Charger 163.8W for 48V E-bike, E-scooter and Robot

Fuyuang 54.6V 3A 13S Smart Li-ion Battery Charger 163.8W for 48V E-bike, E-scooter and Robot

Name: Fuyuang 54.6V 3A 13S Smart Li-ion Battery Charger 163.8W for 48V E-bike, E-scooter and Robot
Brand: Fuyuang
Rating: 5.0 (37 reviews)

The Fuyuang FY5463000 is a 54.6V 3A desktop Li-ion battery charger rated 163.8W output, engineered for 13S 48V lithium packs used on electric bikes, electric scooters, robots and scooters. A universal 100-240Vac input makes it usable worldwide. Charging runs on a CC-CV-floating / shut-off profile, so the pack fills safely and the charger stops when charging is complete. The fanless design cools by free air convection for quiet operation, and short-circuit, overload, over-voltage and over-temperature protection guard both charger and battery. An LED indicator shows charging status. Built by Fuyuan Electronic Co., Ltd since 2005, with 108,000 m2 of production space, a CNAS-standard EMC laboratory, 3,000+ developed models from 60W to 10KW, and a 3-year warranty.

Model:
FY5463000
Brand:
Fuyuang
Code:
FY5463000


Availability:

Product Overview

The FY5463000 is a 54.6V 3A smart Li-ion battery charger for 13S 48V lithium battery packs, delivering 163.8W from a universal 100-240Vac 50/60Hz input. It is designed for e-bikes, electric scooters, robots and other light electric vehicles that need a compact desktop charger. Charging follows a CC-CV-floating / shut-off profile that keeps the pack full without overcharging, while the fanless housing cools by free air convection.

Key Features

• Smart CC-CV-floating charging with automatic shut-off • 163.8W output at 54.6V 3A for 13S 48V lithium packs • Universal 100-240Vac 50/60Hz input for worldwide use • Fanless design, cooled by free air convection, low noise • 94-V0 fireproof PC case with fuses on both input and output • Short-circuit, overload, over-voltage and over-temperature protection • LED indicator: red while charging, green when charging is complete • 3-year warranty; modified and customized designs accepted

Technical Specifications

• Model: FY5463000 • Input: 100-240VAC, 50/60Hz • Output: 54.6V 3A • Output power: 163.8W • Battery type: Li-ion, 13S 48V pack • Charging mode: CC - CV - floating charging / shut off • Charging efficiency: 90% • Cooling: fanless, free air convection • Housing material: PC fireproof material • Dimension: 178*80*46MM • Weight: 0.80kgs • Protection: short circuit, overload, over voltage, over temperature • Certification: UL, FCC, CB, CE, GS, UKCA, PSE, SAA, RCM, KC, KCC, CCC, RoHS, REACH • Warranty: 3 years • MOQ: 100 PCS

Applications

• Electric bikes and e-bikes • Electric scooters and motorcycles • Robots and humanoid robots • Cleaning robots • Electric wheelchairs and power wheels • Portable power stations • Drones

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on this platform, including custom output voltage and current, private labeling, LOGO printing and connector selection. Engineering support is backed by a CNAS-standard EMC laboratory, so compliance testing can be prepared before formal certification and the development cycle can be shortened. Every unit is 100% factory inspected and receives 4-8 hours of full-load burn-in, and this product carries a 3-year warranty. Standard MOQ is 100 PCS.
