Fuyuang 330W GaN Battery Charger 14.6V-84V for Electric Scooter, Robot, 3D Printer and E-Bike

Fuyuang 330W GaN Battery Charger 14.6V-84V for Electric Scooter, Robot, 3D Printer and E-Bike

Name: Fuyuang 330W GaN Battery Charger 14.6V-84V for Electric Scooter, Robot, 3D Printer and E-Bike
Brand: Fuyuang
Rating: 5.0 (88 reviews)

The Fuyuang FY5460000 is a 330W GaN battery charger that pairs high output with a compact 198 x 94.5 x 42 mm housing. Gallium nitride switching keeps efficiency at 95% with less heat than conventional silicon designs, and the 100-240Vac 50/60Hz input works on any mains supply. Output options include 14.6V 20A, 16.8V 18A, 20V 15A, 24V 12A/13A, 29.2V 10A, 29.4V 10A, 42V 7A, 48V 6A/7A, 54.6V 6A, 58.4V 5A, 67.2V 4.5A and 84V 3.5A, covering lithium and LiFePO4 packs from 12V to 72V. Applications span electric scooters, robots, 3D printers, industrial equipment and medical devices. Manufactured by Fuyuan Electronic Co., Ltd since 2005, with 108,000 m2 of production space, 450 employees, a CNAS-standard EMC laboratory, 3,000+ developed models from 60W to 10KW, and a 3-year warranty on this product.

Model:
FY5460000
Brand:
Fuyuang
Code:
FY5460000


Availability:

Product Overview

The FY5460000 delivers 330W in a compact GaN desktop charger, aimed at electric scooters, robot battery packs, 3D printers, power tools and portable equipment. It replaces bulkier silicon chargers while keeping the same output. Outputs from 14.6V 20A to 84V 3.5A cover 12V, 24V, 36V, 48V and 72V battery packs, and full protection guards against over-charging, over-current, over-voltage and short circuit. The private mould ABS and fireproof PC housing is supplied in black.

Key Features

• 330W GaN charger with a compact 198 x 94.5 x 42 mm housing • High efficiency switching with 95% conversion efficiency • Wide output range from 14.6V 20A up to 84V 3.5A • Outputs include 24V 12A / 48V 6A / 29.2V 10A / 54.6V 6A / 67.2V 4.5A / 84V 3.5A • Universal 100-240Vac 50/60Hz input • Protection: fireproof, over-charging, over-current, over-voltage and short circuit • Private mould housing in ABS and fireproof PC; colour black • Plug types AU, EU, UK, US, JP

Technical Specifications

• Model: FY5460000 • Input: 100-240Vac 50/60Hz • Output power: 330W • Output variants: 14.6V 20A / 16.8V 18A / 20V 15A / 24V 12A / 24V 13A / 29.2V 10A / 29.4V 10A / 42V 7A / 48V 6A / 48V 7A / 54.6V 6A / 58.4V 5A / 67.2V 4.5A / 84V 3.5A • Efficiency: 95%; size 198*94.5*42 mm • Housing material: ABS, fireproof PC; colour black • Certification: CE, FCC, RoHS, UKCA, UL, GS, KC, PSE • MOQ: 100 PCS

Applications

• Electric scooters and e-bikes • Service and industrial robots • 3D printers • Electric tools • Medical devices • Home security systems and household appliances

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on this platform, covering custom output voltage and current, charging profiles, DC connectors, AC plugs, cable length, housing colour, private labeling, LOGO printing and packaging. Engineering work is supported by a CNAS-standard EMC laboratory, so compliance testing can be prepared before formal certification and the development cycle shortened; custom projects can reach engineering completion in as little as 10 days. Every unit is covered by a 3-year warranty, is 100% factory inspected and receives 4-8 hours of full-load burn-in. Standard MOQ for this item is 100 PCS. Certifications held on this platform include CE, FCC, RoHS, UKCA, UL, GS, KC and PSE.
