Fuyuang FY4804000 12V 5A Class 2 LED Driver and 48W-60W Power Adapter for LED Lighting

Fuyuang FY4804000 12V 5A Class 2 LED Driver and 48W-60W Power Adapter for LED Lighting

Name: Fuyuang FY4804000 12V 5A Class 2 LED Driver and 48W-60W Power Adapter for LED Lighting
Brand: Fuyuang
Rating: 5.0 (1 reviews)

The Fuyuang FY4804000 is a Class 2 LED driver and power adapter with a 100-240Vac 50/60Hz input. Output versions include 12V 2A, 12V 1.5A, 12V 3A and 12V 5A, with power ratings of 48W and 60W. Efficiency is above 89% and cooling is fanless by free air convection, avoiding fan noise and dust ingress. Protection covers short circuit, overload, over-voltage and over-temperature. The housing is fireproof PC material in black, with a DC output port. Compliance for this model covers UKCA, CE, PSE and KC. Fuyuan Electronic Co., Ltd has manufactured LED power supplies since 2005 and covers every unit with a 3-year warranty.

Model:
FY4804000
Brand:
Fuyuang
Code:
FY4804000


Availability:

Product Overview

The FY4804000 is a Class 2 LED driver and power adapter with a 100-240Vac 50/60Hz input. Available output versions include 12V 2A, 12V 1.5A, 12V 3A and 12V 5A at 48W or 60W. The driver cools without a fan by free air convection, so it runs quietly and does not draw dust into the housing. Efficiency is above 89%, and short circuit, overload, over-voltage and over-temperature protection are built in.

Key Features

• Class 2 LED driver and power adapter • Output versions: 12V 2A, 12V 1.5A, 12V 3A, 12V 5A • Power ratings of 48W and 60W • 100-240Vac 50/60Hz universal input • Efficiency above 89% • Fanless design, cooled by free air convection • Short circuit, overload, over-voltage and over-temperature protection • Fireproof PC housing with DC output, OEM/ODM design available

Technical Specifications

• Model: FY4804000 • Product type: Class 2 LED driver / power adapter • Input: 100-240Vac, 50/60Hz • Output: 12V 2A / 12V 1.5A / 12V 3A / 12V 5A • Output power: 48W / 60W • Efficiency: >89% • Cooling: fanless, free air convection • Protection: short circuit, overload, over-voltage, over-temperature • Port: DC output • Material: PC fireproof material • Color: black • Certification: UKCA, CE, PSE, KC • Warranty: 3 years

Applications

• LED lighting and LED lamps • Class 2 constant current LED lighting • Indoor and outdoor lighting fixtures • Signage and decorative lighting • General electric equipment

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on this LED driver platform, including custom output voltage and current, custom DC connector, private labeling and LOGO printing. The CNAS-standard EMC laboratory supports pre-compliance testing before formal certification. Every driver is 100% factory inspected, burn-in tested at full load for 4-8 hours and covered by a 3-year warranty. MOQ is 100 PCS.
