Fuyuang FY1205000 12V 5A Plug-in AC DC Power Adapter 60W Switching Power Supply for CCTV, LED Lighting and Medical Products

Fuyuang FY1205000 12V 5A Plug-in AC DC Power Adapter 60W Switching Power Supply for CCTV, LED Lighting and Medical Products

Name: Fuyuang FY1205000 12V 5A Plug-in AC DC Power Adapter 60W Switching Power Supply for CCTV, LED Lighting and Medical Products
Brand: Fuyuang
Rating: 5.0 (30 reviews)

The Fuyuang FY1205000 is a compact plug-in AC DC power adapter rated 12V 5A with efficiency above 88%. It belongs to the Fuyuang 60W adapter platform, which also covers 12V, 24V, 48V and 58V output variants for different loads. Short circuit, overload, over-voltage and over-temperature protection keep both the adapter and the connected device safe, while the housing can be supplied in black, white or a customized colour. Typical uses are CCTV and security systems, lighting, robots, scooters and medical products. Fuyuan Electronic Co., Ltd has manufactured power supplies since 2005, runs 108,000 m2 of production space across two bases in Dongguan and Yongzhou, and covers this adapter with a 3-year warranty plus 100% factory inspection.

Model:
FY1205000
Brand:
Fuyuang
Code:
FY1205000


Availability:

Product Overview

The FY1205000 is a plug-in AC DC switching power adapter rated 12V 5A in the Fuyuang 60W adapter series. It converts mains AC input into a regulated 12V DC output for CCTV cameras, LED lighting, medical products and small electric equipment. Efficiency is above 88%, and protection covers short circuit, overload, over-voltage and over-temperature events. The plug-in format keeps installation simple, and the enclosure is available in black, white or a customized colour.

Key Features

• Plug-in AC DC power adapter with a 12V 5A DC output • Part of the 60W adapter platform also covering 12V, 24V, 48V and 58V variants • Efficiency above 88% • Short circuit, overload, over-voltage and over-temperature protection • Available in black, white or customized colours • Compact 113 x 43.5 x 30 mm housing weighing 0.35 kg • UL, cUL, GS, CE, SAA, KC, PSE, CB, FCC, RoHS and REACH certified • 3-year warranty on every unit

Technical Specifications

• Model: FY1205000 • Product type: AC DC plug-in power adapter • Output: 12V 5A DC • Power: 60W adapter platform • Efficiency: >88% • Protection: short circuit, overload, over-voltage, over-temperature • Connection: plug-in with DC output • Dimension: 113 x 43.5 x 30 mm • Weight: 0.35 kg • Color: black, white or customized • Certification: UL, cUL, GS, CE, SAA, KC, PSE, CB, FCC, RoHS, REACH • Warranty: 3 years

Applications

• CCTV and security monitoring cameras • LED lighting • Medical products • Robots and robot vacuums • Scooters and light electric vehicles • General electric equipment

Customization & Service

OEM and ODM projects are supported on this platform, including custom output voltage and current, custom DC connector, private labeling and LOGO printing. Fuyuan Electronic Co., Ltd operates a CNAS-standard EMC laboratory, so EMC and safety performance can be verified before formal certification testing to shorten the approval cycle. Every unit is 100% factory inspected and carries a 3-year warranty. MOQ for this model is 200 PCS.
