Fuyuang FY5803000 58.4V 3A 175W Lead-Acid / AGM Battery Charger for 48V Electric Motorcycle and E-Scooter Batteries

Fuyuang FY5803000 58.4V 3A 175W Lead-Acid / AGM Battery Charger for 48V Electric Motorcycle and E-Scooter Batteries

Name: Fuyuang FY5803000 58.4V 3A 175W Lead-Acid / AGM Battery Charger for 48V Electric Motorcycle and E-Scooter Batteries
Brand: Fuyuang
Rating: 5.0 (40 reviews)

The Fuyuang FY5803000 is a 58.4V 3A desktop charger for 48V lead-acid battery packs, including AGM and gel types used on electric motorcycles, e-scooters and small electric vehicles. Input is a universal 100-240V 50/60Hz, and the model is rated 175W or 205W depending on configuration. Short circuit, overload, over-voltage and over-temperature protection are built in, with over-current and over-voltage protection at pack level to keep lead-acid batteries from being stressed. Charging efficiency is above 89%, and the fanless plastic case cools by natural air convection to avoid fan wear and dust ingress on road vehicles. Fuyuan Electronic Co., Ltd has built chargers and power supplies since 2005 in 108,000 m2 of production space, with 3,000+ developed models from 60W to 10KW and a 3-year warranty on this product.

Model:
FY5803000
Brand:
Fuyuang
Code:
FY5803000


Availability:

Product Overview

The FY5803000 charges 48V lead-acid battery packs at 58.4V 3A, the voltage needed to bring a 4-cell lead-acid string to full charge. It is intended for electric motorcycles, e-scooters and comparable light electric vehicles that are charged from a wall socket every day. The unit runs on 100-240V 50/60Hz and outputs 58.4V 3A with a custom option, giving 175W or 205W of charging power in a compact 178*80*46mm housing that weighs 0.87kg.

Key Features

• 58.4V 3A DC output for 48V lead-acid, AGM and gel battery packs • 100-240V 50/60Hz wide-range AC input • Custom output setting available to match a specific battery pack • Rated output power 175W / 205W • Charging efficiency above 89% • Short circuit, over-load, over-voltage and over-temperature protection • Fanless plastic case with PC fireproof material, cooled by free air convection • Compact 178*80*46MM enclosure weighing 0.87kgs

Technical Specifications

• Model: FY5803000 • Item: 58.4V 3A AGM battery charger, 48V lead-acid charger • AC input: 100-240V 50/60Hz (100-240V 2.2A) • DC output: 58.4V 3A / 3.5A, custom available • Output power: 175W / 205W, custom • Battery type: 4-cell lead-acid battery pack (AGM / gel) • Charging efficiency: above 89% • Dimension: 178*80*46MM • Weight: 0.87kgs • Housing: PC fireproof material • Protection: short circuit, over-load, over-voltage, over-temperature • Certification: UL, FCC, cUL, CE, RoHS, CB, GS, SAA, RCM, PSE, CCC • MOQ: 100 PCS

Applications

• Electric motorcycles and mopeds • Electric scooters and e-scooters • 48V AGM and gel battery packs • Light electric vehicles and golf cars • Battery replacement and service workshops • Fleet maintenance and charging stations

Customization & Service

Fuyuan Electronic Co., Ltd supports OEM and ODM projects on this model, including custom output voltage and current, DC connector and cable, housing colour, private labeling, LOGO printing and packaging. The in-house CNAS-standard EMC laboratory screens designs before certification submission. Every charger is 100% factory inspected and the product carries a 3-year warranty. Standard MOQ is 100 PCS.
