Fuyuang DC-DC On-Board Battery Charger 10-30V Input to 29.4V 2A 58.8W for Ebike Scooter, 60W-200W Li-ion Charger

Fuyuang DC-DC On-Board Battery Charger 10-30V Input to 29.4V 2A 58.8W for Ebike Scooter, 60W-200W Li-ion Charger

Name: Fuyuang DC-DC On-Board Battery Charger 10-30V Input to 29.4V 2A 58.8W for Ebike Scooter, 60W-200W Li-ion Charger
Brand: Fuyuang
Rating: 5.0 (90 reviews)

The Fuyuang FY2942000 is a DC-DC on-board battery charger that steps a 10-30V DC supply up to a 29.4V 2A charging output rated 58.8W. Both input and output are customizable, and the platform covers 60W, 80W, 100W, 120W and 200W power levels with additional outputs at 29.4V 3A, 42V 2A, 42V 3A, 54.6V 2A and 54.6V 3A. Efficiency reaches 95%. The charger is intended for on-board installation on e-bikes and scooters running 12V, 24V, 36V, 48V and 60V systems, and works with lithium-ion battery packs. DC connector options include 5.5x2.1mm, 5.5x2.5mm, XLR and XT30/60, and the housing uses PC fireproof material. Fuyuan Electronic Co., Ltd has been manufacturing since 2005 with 108,000 m2 of production space across two bases, 450 employees and 3,000+ developed models from 60W to 10KW. This charger is covered by a 3-year warranty with 100 PCS minimum order quantity.

Model:
FY2942000
Brand:
Fuyuang
Code:
FY2942000


Availability:

Product Overview

The FY2942000 is a DC-DC on-board battery charger designed for vehicles where an AC charger cannot be carried. It accepts 10-30V DC input and delivers a regulated 29.4V 2A charging output at 58.8W, both of which can be customised for specific battery systems. The platform ranges from 60W to 200W and covers 29.4V 2A, 29.4V 3A, 42V 2A, 42V 3A, 54.6V 2A and 54.6V 3A outputs, making it suitable for e-bikes and scooters running 12V to 60V lithium battery packs.

Key Features

• DC-DC on-board charger with 10-30V input (customisable) • 29.4V 2A (58.8W) charging output, also customisable • Platform output power from 60W to 200W • 95% efficiency • Charges lithium-ion battery packs for e-bikes and scooters • Designed for on-board installation on 12V, 24V, 36V, 48V and 60V systems • DC connectors: 5.5x2.1mm, 5.5x2.5mm, XLR, XT30, XT60, customisable • PC fireproof material with multi-layer protection

Technical Specifications

• Model Number: FY2942000 • Brand: Fuyuang • Product name: DC/DC on-board e-bike scooter lithium ion battery charger • Input: 10-30V DC (or customisation) • Output: 29.4V 2A (58.8W) (or customisation) • Output voltage options: 29.4V 2A, 29.4V 3A, 42V 2A, 42V 3A, 54.6V 2A, 54.6V 3A • Output power: 60W, 80W, 100W, 120W, 200W • Efficiency: 95% • DC connector: 5.5x2.1mm, 5.5x2.5mm, XLR, XT30/60, customisable • Protection: fireproof, over-charging, over-current, over-voltage, short circuit • Material: PC fireproof material • Certification: CE, FCC, RoHS, UKCA, UL, GS, ETL • Warranty: 3 years; MOQ: 100 PCS

Applications

• On-board charging for e-bikes and scooters • Electric power tools • Industrial equipment • Medical devices • Motorcycles and personal mobility vehicles

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on this DC-DC platform: input voltage range, output voltage and current, connector type, cable length, housing and packaging can all be adapted. A CNAS-standard EMC laboratory supports compliance preparation before formal certification. Every unit is 100% factory inspected and covered by a 3-year warranty. Minimum order quantity is 100 PCS.
