Fuyuan 36V 5A 6A Regulated SMPS AC DC Switching Power Supply for LED Lighting and E-bike

Fuyuan 36V 5A 6A Regulated SMPS AC DC Switching Power Supply for LED Lighting and E-bike

Name: Fuyuan 36V 5A 6A Regulated SMPS AC DC Switching Power Supply for LED Lighting and E-bike
Brand: Fuyuang
Rating: 5.0 (84 reviews)

The Fuyuan FY3605000 is a regulated SMPS power adapter supplying 36V at 5A or 6A from a 100-240VAC input. It is used for LED lighting as well as electric bikes, hoverboards and electric scooter motors. Efficiency is above 88%, and short-circuit, over-current and over-voltage protection are built in. The desktop enclosure measures 178*60*35mm at 0.78kgs and is available in black, white or customized colour. Manufactured by Fuyuan Electronic Co., Ltd since 2005, with 108,000 m2 of production space, a CNAS-standard EMC laboratory, 3,000+ developed models from 60W to 10KW, and a 3-year warranty.

Model:
FY3605000
Brand:
Fuyuang
Code:
FY3605000


Availability:

Product Overview

The FY3605000 is a regulated SMPS power adapter and AC DC switching power supply delivering 36V DC at 5A or 6A from a 100-240VAC input. It is widely used for LED lighting and for e-bike, hoverboard and scooter motor power. The desktop housing measures 178*60*35MM at 0.78kgs, and the output is regulated for stable operation of lighting and motor loads.

Key Features

• 36V DC output at 5A or 6A • Regulated SMPS switching power supply design • Universal 100-240VAC input • Efficiency above 88% • Short circuit, over-current and over-voltage protection • Compact desktop housing, 178*60*35mm at 0.78kgs • Suits LED lighting, e-bikes, hoverboards and scooter motors • 3-year warranty; OEM/ODM accepted

Technical Specifications

• Model: FY3605000 • Product name: 36V 5A 6A SMPS power adapter LED lighting AC DC switching power supply • Input voltage: 100-240VAC • Output type: DC • Output: 36V 5A / 6A • Efficiency: above 88% • Connection: desktop • Dimension: 178*60*35mm • Weight: 0.78kgs • Color: black / white or customized • Protection: short circuit, over-current, over-voltage • Usage: LED lighting, electric bikes, hoverboard, electric scooter motor • Certification: UL, CUL, GS, CE, BS, SAA, KC, PSE, CB, FCC, EMC, RoHS, REACH • Warranty: 3 years • MOQ: 100 PCS

Applications

• LED lighting • Electric bikes and e-bikes • Hoverboards • Electric scooter motors • General DC equipment

Customization & Service

Fuyuan Electronic Co., Ltd accepts OEM and ODM projects on this platform, including custom output voltage and current, colour and housing, private labeling, LOGO printing and connector selection. Engineering support is backed by a CNAS-standard EMC laboratory, so compliance testing can be prepared before formal certification and the development cycle can be shortened. Every unit is 100% factory inspected and receives 4-8 hours of full-load burn-in, and this product carries a 3-year warranty. Standard MOQ is 100 PCS.
